TYPE N
TYPE F
D. TYPE F - Remove the torque arm, outer body
seal, and spring together, then remove the
hex-hole washer.
E. TYPE F - Tip the bike to allow the spring
adjuster plate and lockring retainer to fall into
your hand.
D. TYPE N - Remove the torque arm, spring
adjuster, outer body seal, and spring together,
then remove the hex-hole washer.
E. TYPE N - Tip the bike and allow the lockring
retainer to fall into your hand.
6
