Installation
Required Tools and Materials
l Small slotted screwdriver with 5/64” or 2 mm blade width — for connecting power when not using Power
over Ethernet.
Camera Package Contents
Ensure the package contains the following:
l Avigilon™ High Definition IP Dome Camera
l Terminal block
l T20 Torx key
l Teflon Sealing Tape
Installation Steps
Complete the following steps to install the device:
Removing the Dome Cover 6
Mounting and Aiming Video Analytics Cameras 6
Mounting the DomeCamera 6
Connecting Cables 10
Assigning an IP Address 10
Accessing the Live VideoStream 10
Aiming the Dome Camera 11
(Optional) Configuring Onboard Storage 11
Installing the Dome Cover 11
Focusing the DomeCamera 11

5 Installation
