Aiming the Dome Camera
1. Loosen the pan and tilt lock screws on the camera.
2. Turn the lens to the desired direction by panning and tilting the lens.
3. Once satisfied, tighten the pan and tilt lock screws to secure the dome camera’s position.
4. Rotate the azimuth control ring to set the image to the correct angle.
5. In the Camera Installation Tool or camera web browser interface, adjust the camera’s Image and Display
settings. From either applications, you can set the desired zoom position, and change the image rotation.
(Optional) Configuring Onboard Storage
To use the camera’s onboard storage feature, you must insert an SD card into the SD card slot.
It is recommended that the SD card have a capacity of 8GB or more, and a write speed of class 6 or better. If the
SD card does not meet the recommended capacity or write speed, the performance of the onboard storage
may suffer and result in the loss of frames or footage.
1. Insert an SD card into the camera.
CAUTION — Do not force the SD card into the camera or you may damage the card and the
camera. The SD card can only be inserted in the orientation shown on the camera.
2. Access the camera’s web interface to enable the onboard storage feature. For more information, see the
Avigilon High Definition H.264 Camera Web Interface User Guide.
Installing the Dome Cover
1. Rotate the black shield located inside the dome bubble so that it does not block the camera’s field of
view.
2. Attach the dome cover to the base by tightening the screws with the provided Torx key.
3. Remove the plastic cover on the dome bubble.
Focusing the DomeCamera
NOTE: Ensure this procedure is performed after the dome cover is installed, so the focus shift caused by the
dome bubble’s refraction can be accomodated.
l In the Camera Installation Tool or camera web browser interface, use the camera’s Image and Display
settings to focus the camera lens.
a. Click the Auto Focus button to focus the lens.
b. If the desired focus was not achieved, use the focus near and far buttons to adjust the focus.
CAUTION — Do not attempt to adjust the focus and zoom on the camera manually or the camera lens
may become damaged
For More Information
Additional information about setting up and using the device is available in the following guides:
