AVL DiTEST ADS 310/340
ENGLISH
Start-Up – Short Instruction
9
START-UP
WARNING
The machine must be taken into service by expert personnel strictly complying with these instructions.
Unpacking
NOTE
AVL DiTEST ADS 310/340 comes without the refrigerant bottle CO
2
(R744). This is to avoid any shipping damage.
1. Cut the packing tape and remove the carton.
2. Carefully remove the protective foil from the AVL DiTEST ADS 310/340.
3. Use the scissors/side cutter to cut the four zip ties used to additionally secure the AVL DiTEST ADS 310/340 to
the pallet.
4. Keep the carton and the protective film for possible returns.
WARNING
Crushing hazard!
AVL DiTEST ADS 310/340 may tilt and fall off the pallet.
Carefully lift the AVL DiTEST ADS 310/340 off the pallet with the help of a 2
nd
person.
Installation location / stability
WARNING
Make sure that the AVL DiTEST ADS 310/340:
 is standing horizontally and stable
 is in a room with adequate ventilation and/or air exchange
 has a minimum distance of 10 cm to other objects
 is protected from rain, humidity, direct sunlight and/or excessive dust
 is not operated in an explosive environment
Checking vacuum pump oil
Check the oil level by means of the inspection glass.
If necessary, complete the vacuum pump oil,
see user manual, chap. 5.2.1.
Connection to the power supply
WARNING
Only use the provided power cable! Observe the specifications on the rating plate!
When servicing the machine, only use original AVL DiTEST spare parts!
Install the AVL DiTEST ADS 310/340 in such a way that the user has easy access to the power outlet!
