AVM Fritz!WLAN 1750E User Manual

LEDs and Button
The LEDs show the operating status of the FRITZ!WLANRepeater 1750E:
on fl ashing
Quality of the wireless
radio signal
Connection to the wireless access point is
interrupted
Power
The FRITZ!WLANRepeater
1750E is ready for
operation
 The FRITZ!WLANRepeater 1750E is being
started
 Updating FRITZ!OS
WLAN
Wireless LAN function
enabled
 WPS in progress; fl ashes fast: WPS was
aborted
 Enabling Mesh WiFi
 Adopting the wireless LAN settings
LAN
Network device connected
all
Loading factory settings
With the “WPS” button you operate the FRITZ!WLAN Repeater 1750E:
Press the WPS button
Initiate WPS / enable Mesh WiFi
1second
Connect with another access point
6seconds
Factory settings
15seconds
 Measures: 76.5 x 155 x 62.6mm
 Supply voltage: 230V, 50 Hz AC
 Operating temperature: 0°C to +40°C
 Active power (max.): 5.5W
 Active power (Ø): 3,3W
 Weight: 151g
 Gigabit Ethernet: network port over
RJ45 socket (10/100/1000 Base-T)
 6 integrated antennas
 Dual Wireless AC and N (2.4 GHz and
5 GHz concurrently)
 Wireless LAN: 802.11ac and 802.11n,
downward compatible to 802.11g/b
and a
 Wireless LAN: up to 1300Mbit/s*
(5 GHz), up to 1750 Mbit/s* (2,4 GHz):
(*gross, the achievable throughput
rates are lower)
 WPA, WPA2 (802.11i)
See the FRITZ!Box manual
for comprehensive technical
specifi cations.
Radio Frequencies and Transmitter
Power
 Wireless LAN radio technology at
2.4 GHz range: 2.4 GHz – 2.483 GHz,
maximum 100 mW
 Wireless LAN technology at 5 GHz
range: 5.15 GHz – 5.35 GHz, maximal
200 mW plus 5.47 GHz – 5.725 GHz,
maximum 1000 mW
 In the 5-GHz band for wireless LAN,
the range from 5.15 GHz to 5.35 GHz
is intended only for indoor use. This
restriction or requirement is eff ective
in the EU member states AT, BE, BG,
CY, CZ, DE, DK, EE, EL, ES, FI, FR, HR,
HU, IE, IT, LT, LU, LV, MT, NL, PL, PT, RO,
SE, SI, SK, UK.
Technical Specifi cations
12 13

AVM Fritz!WLAN 1750E Specifications

General

Frequency Bands	2.4 GHz, 5 GHz
LAN Ports	1 x Gigabit Ethernet
Encryption	WPA2, WPA, WEP
WPS	Yes
Power Supply	230V, 50Hz
Wi-Fi Standard	IEEE 802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a
Maximum Data Rate	1300 Mbit/s
