4.4 SETUP mode
To enter the SETUP mode from either the PFD or HSI mode keep the rotation knob
pressed for 5 seconds.
The SETUP mode provides you information regarding the software version, enabled
COM ports, V-speed values and display brightness.
In the SETUP mode push the rotation knob to enter the “SETUP” menu:
In the “SETUP” menu you can enter the following menu’s:
• CALIBRATE: To calibrate the compass, horizon and altimeter.
• DATABASE: To update the navigation POI’s and manage user data points.
• SETUP: To change preference settings like display brightness, configure the aircraft
specific V-speed values, change units measurements and reset all settings to
factory default.
Note: For compass and horizon calibration see Chapter 3. For NMEA-OUT settings see
paragraph 4.5.
Aircraft Specific V-speed reference values
Select “SPEEDS” in the “SETUP” menu to enter the V-speed reference values shown
on the bottom of the SETUP mode.
Rotate the rotation knob to change values and push the rotation knob to confirm.
Refer to the aircraft operating manual to find the correct values of your aircraft.
Note: In the “SETUP” menu select your preference unit for speeds: knots, kph, mph, m/s.
Navigation POI management
Ultra is preloaded with Jeppesen navigation POI’s: Airports, NDB’s and VOR’s.
In the “DATABASE” menu you can choose “IMPORT” to update navigation POI’s on the
Ultra through the microSD card. Make sure the microSD card is inserted in the Ultra.
Note: To update the navigation POI’s on your Ultra visit www.avmap.it or contact
orders@avmap.it. Follow the update instructions that are provided together with the
POI purchase.
User Data
In the “DATABASE” menu select “USER DATA” to enter the user database menu.
In the “USER DATA” menu you can enter the following menu’s:
• IMPORT: Import a database file prepared by AvMap for specific coverages. Check
which additional database files are available at the Ultra product page at avionics.
avmap.it.
• EDIT: Edit existing user points information.
• NEW: Create a new user point. Insert ID, Name, LAT/LON, Altitude, and desired
information in info-field 1 and info-field 2.
• DELETE: Delete existing user points.
Display brightness
Select “BRIGHTNESS” in the “SETUP” menu to adjust the display brightness. Use the
rotation knob to change the display brightness and conrm by pushing the rotation knob.
