Installation
7
2. Locate your next input cable. Repeat step 1 until all computers are properly
attached to the SwitchView SC.
3. Locate the power cord that came with your SwitchView SC unit. Plug it into the
IEC power connector on the unit and make sure that the power switch is off.
Then, plug the other end of the power cord into an appropriate AC wall outlet.
4.. Power up your SwitchView SC fi rst, then all attached computers.
MOUSE PORT
VIDEO PORT
KEYBOARD PORT
To Next Page
