Audio Output Logic:
You can extract audio from toslink or balance 2CH Audio. Audio outputs are an un-decoded output. This
means that what goes in, is what goes out.
1. 2CH Analog Port - Supports 2CH PCM audio only, which is ideal for 2 Channel systems and
zoned audio systems.
2. Toslink Audio Port - Supports PCM, LPCM (up to 7CH), Dolby Digital, Dolby Digital Plus, DTS,
DTS-HD, DTS Master Audio, which is ideal for multi-channel audio systems and older AVRs that
don't support 18Gbps.
3. Need to down-mix for combination, uncompressed and 2CH systems? Check out the AC-
AVDM-AUHD and AC-ADM-COTO
4. NOTE - The 2CH Analog port and the Toslink port are mirrored. If the audio codec coming into
the AC-MX-42 is above 2-Channel, the Analog port will be silent, however the audio will still come out
of Toslink.
Auto Switching Logic:
When the AC-MX-42 is in "Auto" mode the logic is to switch to the most recently plugged in device
based on a Hot Plug Event. You can have either HDMI OUTPUT set on auto individually or they can both
be on together.
See examples:
Factory Reset:
There is an easy way to reset all settings on this unit. It is especially useful if a static IP is set and the
network changes, you can reset it.
• To preform a factory reset:
Press and hold both "Audio Select" and "Output 1 Scaler Select" buttons for 5 seconds. All
LEDs will flash one time indicating it is complete. All settings will now be reset including the IP
address abck to 192.168.001.239
1. When a new source device (like a PC) is plugged into the AC-MX-42, it automatically
switches to that input.
2. When an active source device is disconnected, the AC-MX-42 is automatically switched back
to the last source plugged in before it (so long as it is still active). It will continue to
backtrack until it finds an active source. If no active source is found it will stop searching
after one cycle.
3. If you are collaborating and a PC is connected, when a new PC is plugged into the matrix it
will activate the new input on the outputs that are set to "Auto" - You can override by
pressing the front panel, or sending a remote serial or LAN command as well.
