Macro
Macro
ENT 
Macro #
1 (1.. 64)
Operat. #
1 (1.. 8)
Operation Type:
Arm. HO Part.
Label
The Macros (maximum 64) allow the user to carry out various operations at the same time (maximum 8) using
the same command:
Type of Operation:
• Arm. ON Part.
• Arm. HO Part.
• Arm. AR Part.
• Arm. PE Part.
• Disarm. Part.
Example: Starting in ON modality of Partition 3, disabling the input and output timers of
the timed zones associated with this Partition.
• Activ. O.C.
• Deactiv. O.C.
Example: Activation of the O. C. 3
• Exclude zone:
• Re-incl. zone:
Example: Exclusion of zone 5
Label: it is possible to associate a description of 16 alphanumerical digits for every Macro
Press (CLR) to vary
To access other entries press () or ()
Writing keys::
(1)abc1 (2)def2 (3)ghi3 (4)jkl4 (5)mno5 (6)pqr6 (7)stu7 (8)vwx8 (9)yz. (0)_’0
Press arrows () and () to position the cursor
Press (ENT) to conrm
Operation Type:
Arm. HO Part.
Partition #
3 (1.. 8)
Zone timers OFF
YES
With this type of operation it is possible to enter a preselected
modality, ON - HOME - AREA - PERIMETER, and disarm and
manage the “Zone timers OFF” function of the Partition se-
lected in the submenu.
Operation Type:
Attiva O.C.
O.C. #
3 (1.. 32)
With this type of operation it is possible to activate or deacti-
vate the Open Collector selected in the submenu.
Operation Type:
Escludi zona:
Zone number
5 (1.. 32)
With this type of operation it is possible to exclude or re-inclu-
de the zone selected in the sub-menu.
Partition #
1 (1.. 8)
Zone timers OFF
NO
to following
