Avtron Model K875A Load Bank
TABLE OF CONTENTS (Cont.)
OPTIONS - Refer to Section VI (K875A OPTIONS LIST) of this manual. The following
drawings apply to the various options. Only drawings for the options provided have
been included in this manual. Not all options can be installed in the same unit.
Installed options are marked on the identification tag.
Drawing Option Description
* D27683-1 1 Control Transformer Option, 500 to 2000 kW Load Banks,
(240/120V Control Transformer)
* D27683-2 2 Control Transformer Option, 500 to 2000 kW Load Banks,
(380/110V Control Transformer)
* D27683-3 3 Control Transformer Option, 500 to 2000 kW Load Banks,
(480/120V Control Transformer)
* D27683-4 4 Control Transformer Option, 2001 to 2500 kW Load
Banks, (480/120V Control Transformer)
* D27683-5 5 Control Transformer Option, 2501 to 3000 kW Load
Banks, (480/120V Control Transformer)
* D27683-6 6 Control Transformer Option, 2501 to 3000 kW Load
Banks, (575/115V Control Transformer)
A24925 7 Remote Control Unit, Mounted (Left Side)
* B26013 8 Overvoltage Protection
* B26019 9 Elapse Time Meter
* D27682-1 10 1 kW Resolution (for 480 Volt Load Banks)
* D27682-2 11 1 kW Resolution (for 240/480 Volt Load Banks)
A25057-1 12 Intake Overtemp Protection
A25057-2 13 Intake Overtemp Protection
*This drawing includes schematic wiring information.
GAH/kv
1/28/99
