Avtron K875A User Manual

Options
Avtron Model K875A Load Bank
TABLE OF CONTENTS (Cont.)
Drawing Option Description
A25057-3 14 Intake Overtemp Protection
* D27684-1 15 Dual Voltage Control Transformer and Blower Circuit
(for Load Banks Using 5 HP Motor @ 240/480V)
* D27684-2 16 Dual Voltage Control Transformer and Blower Circuit
(for Load Banks Using 10 HP Motor @ 240/480V)
A24744 17 Control/Meter Enclosure, Wallmount
A25353 18 Local Control/Metering Unit, Mounted (Left Side)
** D29421-1 19 Digital Power Metering Option (“D” Style)
(Instruction Manual) (V, A, kW, F, kVAR, PF, kVA), CT Ratio 1200:5
* D27683-7 20 Control Transformer Option, 500 to 2000 kW Load Banks,
(440/115V Control Transformer)
* D29476-1 21 Dual Voltage Control Transformer (500-2000 kW Load
Banks, 240/480 Control Transformer)
* D27685-1 22 Load Shedder Option, Single Board Load Shedder
* D27685-2 23 Load Shedder Option, Dual Board Load Shedder
* D27685-3 24 Load Shedder Option, Single Board Load Shedder
(No component Mounting Panel)
* D27685-4 25 Load Shedder Option, Dual Board Load Shedder
(No component Mounting Panel)
** D29785-1 26 Digital Power Metering Option (“DX” Style)
(Instruction Manual) (V, A, F, kW), CT Ratio 1200/5
** D29785-2 27 Digital Power Metering Option (“DX” Style)
(Instruction Manual) (V, A, F, kW), CT Ratio 2500/5
* This drawing includes schematic wiring information.
** This is a Supplemental Instruction Manual.
GAH/kv
1/28/99
