Avtron K875A - Page 56

Options Parts List
Avtron Model K875A Load Bank
6-11
Form No. 755A
SCHEMATIC
REFERENCE
DESCRIPTION
AVTRON
P/N
QTY/
UNIT
OPTION #16: DUAL VOLTAGE CONTROL XFMR &
BLOWER CIRCUIT (CONT.)
K481 .RELAY, UNDER VOLTAGE 220 VAC -30% to +15% 350583 1
K132 .RELAY; 3P, 25A, 120V, 60 HZ, 351925 1
1-SPDT AUX, DIN RAIL MT
K480 .RELAY; 3P, 25A, 208/240V, 60 HZ, 351924 1
2-SPDT AUX, DIN RAIL MT
T2 .TRANSF, CONT; 50 VA, 440/460/480V PRI, 370528 1
220/230/240V SEC, 50/60 HZ
T1 .TRANSF, CONT: 850 VA, 240/480 VAC PRI, 371148 1
120 VAC SEC, 50/60 HZ
S24, S102 .SWITCH, TOGGLE 360747 2
S100 .SWITCH, PUSHBUTTON, BLACK 361874 1
S101 .SWITCH, PUSHBUTTON, RED 361873 1
OPTION #19: DIGITAL METERING UNIT D29421-1
CT1,2 .TRANSFORMER, CURRENT, 1200:5, 50-400 HZ 370323 2
T100 .TRANSF, POTENTIAL; 480V PRI, 120V SEC, 371046 1
+/-1% ACC @ 1.0 & .95 PF, 50/60 HZ
F100-102 .FUSE CARTRIDGE, 1 AMP, 600 VAC 324449 3
TIME DELAY CLASS CC
XF100-102 .FUSEBLOCK CLASS CC 600V REJ TYPE 324998 1
M1 .DIGITAL POWER METER W/OPTIONS A21028-6 1
85(FREQ)55(KVAR)79(PF)67(KVA)
CR30 .BRIDGE RECTIFIER 35A, 600V 354821 1
C30 .CAPACITOR, ELECTROLYTIC 250V, 100 MFD. 222097 1
OPTION #20: CONTROL TRANSFORMER D27683-7
XF210-212 .FUSEBLOCK 3 POLE 324496 1
F212 .FUSE, CARTRIDGE, 9 AMP, 600V, 324431 1
TIME DELAY, CLASS RK-5
F210,211 .FUSE, 5 AMP, 600V, TIME DELAY CLASS RK-5 324394 2
T1 .TRANSF, CONT: 850 VA, 380/440/550 VAC, 370940 1
50/60 HZ. SECONDARY
