Options Parts List
Avtron Model K875A Load Bank
6-12
Form No. 755A
SCHEMATIC
REFERENCE
DESCRIPTION
AVTRON
P/N
QTY/
UNIT
OPTION #21: DUAL VOLT CONTROL TRANSFORMER D29476-1
CB1 .CIRCUIT BREAKER; 16A, 480V, 2 POLE 310336 1
XF212 .FUSEBLOCK 3 POLE 324496 1
F212 .FUSE, CARTRIDGE, 9 AMP, 600V, 324431 1
TIME DELAY, CLASS RK-5
XF300 .FUSEKIT, TRANSFORMER SECONDARY 324964 1
F300 .FUSE CARTRIDGE 0.5A 250V 324005 1
S100 .SWITCH, PUSH MOM 361662 1
S101 .SWITCH, PUSHBUTTON RED 361661 1
S102 .SWITCH, TOGGLE 125 VAC, 28 VDC 360785 1
K100,240 .RELAY; 3P, 25A, 600 VAC IND, 35A, 350833 2
600 VAC RES, 110/120V, 50/60 HZ
K481 .RELAY, VOLTAGE SENSING; 180-276V PICKUP 350740 1
XK481 .RELAY SOCKET DIN RAIL MOUNT 358280 1
XK481 .CLIP, RETAINER 467522 2
K480 .RELAY; 3P, 25A, 208/240V, 60 HZ, 351924 1
2-SPDT AUX, DIN RAIL MT
T2 .TRANSF, CONT; 50 VA, 440/460/480V PRI, 370528 1
220/230/240V SEC, 50/60 HZ
T1 .TRANSF, CONT: 850 VA, 240/480 VAC PRI, 371148 1
120 VAC SEC, 50/60 HZ
OPTION #22: LOAD SHEDDER D27685-1
K50,51 .RELAY, 3PDT, 120 VAC COIL 351060 2
XK50,51 .RELAY SOCKET DIN RAIL MOUNT 358280 2
XK50,51 .HOLDDOWN SPRING 467550 2
A101 .PRINTED CIRCUIT BOARD ASSY A22829 1
..SCHEMATIC D26034 REF.
DS30 .LAMP, INDICATOR, NEON, PANEL MNT, 329681 1
110/125 VAC, AMBER, .375 MTG. HOLE
S30 .SWITCH, TOGGLE DPDT, 6 TERM, ON-NONE-ON 360747 1
K71 (AUX2) .CONTACT, AUX, SPDT 312361 1
R30 .RESISTOR, 12K OHM, 2W, 5% 119311 1
OPTION #23: LOAD SHEDDER D27685-2
K50,51 .RELAY, 3PDT, 120 VAC COIL 351060 2
XK50,51 .RELAY SOCKET DIN RAIL MOUNT 358280 2
XK50,51 .HOLDDOWN SPRING 467550 2
A101,102 .PRINTED CIRCUIT BOARD ASSY A22829 2
..SCHEMATIC D26034 REF.
DS30 .LAMP, INDICATOR, NEON, PANEL MNT, 329681 1
110/125 VAC, AMBER, .375 MTG. HOLE
S30 .SWITCH, TOGGLE DPDT, 6 TERM, ON-NONE-ON 360747 1
K71 (AUX2) .CONTACT, AUX, SPDT 312361 2
R30 .RESISTOR, 12K OHM, 2W, 5% 119311 1
