Avtron K875A - Page 58

Options Parts List
Avtron Model K875A Load Bank
6-13
Form No. 755A
SCHEMATIC
REFERENCE
DESCRIPTION
AVTRON
P/N
QTY/
UNIT
OPTION #24: LOAD SHEDDER D27685-3
K50,51 .RELAY, 3PDT, 120 VAC COIL 351060 2
XK50,51 .RELAY SOCKET DIN RAIL MOUNT 358280 2
XK50,51 .HOLDDOWN SPRING 467550 2
A101 .PRINTED CIRCUIT BOARD ASSY A22829 1
..SCHEMATIC D26034 REF.
DS30 .LAMP, INDICATOR, NEON, PANEL MNT, 329681 1
110/125 VAC, AMBER, .375 MTG. HOLE
S30 .SWITCH, TOGGLE DPDT, 6 TERM, ON-NONE-ON 360747 1
K71 (AUX2) .CONTACT, AUX, SPDT 312361 1
R30 .RESISTOR, 12K OHM, 2W, 5% 119311 1
OPTION #25: LOAD SHEDDER D27685-4
K50,51 .RELAY, 3PDT, 120 VAC COIL 351060 2
XK50,51 .RELAY SOCKET DIN RAIL MOUNT 358280 2
XK50,51 .HOLDDOWN SPRING 467550 2
A101,102 .PRINTED CIRCUIT BOARD ASSY A22829 2
..SCHEMATIC D26034 REF.
DS30 .LAMP, INDICATOR, NEON, PANEL MNT, 329681 1
110/125 VAC, AMBER, .375 MTG. HOLE
S30 .SWITCH, TOGGLE DPDT, 6 TERM, ON-NONE-ON 360747 1
K71 (AUX2) .CONTACT, AUX, SPDT 312361 2
R30 .RESISTOR, 12K OHM, 2W, 5% 119311 1
OPTION #26: DIGITAL POWER METERING D29785-1
CT1,2 .TRANSFORMER, CURRENT, 1200:5, 50-400 HZ 370323 2
F100-102 .FUSE CARTRIDGE, 1 AMP, 600 VAC 324449 3
TIME DELAY CLASS CC
XF100-102 .FUSEBLOCK CLASS CC, 600V REJ TYPE 324998 1
M1 .DIGITAL POWER METER 3 PHASE A22821 1
OPTION #27: DIGITAL POWER METERING D29785-2
CT1,2 .TRANSFORMER, CURRENT, 2500:5 370336 2
F100-102 .FUSE CARTRIDGE, 1 AMP, 600 VAC 324449 3
TIME DELAY CLASS CC
XF100-102 .FUSEBLOCK CLASS CC, 600V REJ TYPE 324998 1
M1 .DIGITAL POWER METER 3 PHASE A22821 1
OPTION #28: DIGITAL POWER METERING D29785-3
CT1,2 .TRANSFORMER, CURRENT, 1500:5 370159 2
F100-102 .FUSE CARTRIDGE, 1 AMP, 600 VAC 324449 3
TIME DELAY CLASS CC
XF100-102 .FUSEBLOCK CLASS CC, 600V REJ TYPE 324998 1
M1 .DIGITAL POWER METER 3 PHASE A22821 1
