Options Parts List
Avtron Model K875A Load Bank
6-14
Form No. 755A
SCHEMATIC
REFERENCE
DESCRIPTION
AVTRON
P/N
QTY/
UNIT
OPTION #29: DIGITAL METERING UNIT D29421-2
CT1,2 .TRANSFORMER, CURRENT, 3000:5, 370351 2
50-400 HZ, WINDOW SIZE 3.75” X 7.45”
T100 .TRANSF, POTENTIAL; 480V PRI, 120V SEC, 371046 1
+/-1% ACC @ 1.0 & .95 PF, 50/60 HZ
F100-102 .FUSE CARTRIDGE, 1 AMP, 600 VAC 324449 3
TIME DELAY CLASS CC
XF100-102 .FUSEBLOCK CLASS CC 600V REJ TYPE 324998 1
M1 .DIGITAL POWER METER W/OPTIONS A21028-6 1
85(FREQ)55(KVAR)79(PF)67(KVA)
CR30 .BRIDGE RECTIFIER 35A, 600V 354821 1
C30 .CAPACITOR, ELECTROLYTIC 250V, 100 MFD. 222097 1
OPTION #30: DIGITAL METERING UNIT (DZ STYLE) D30857-1
CT1-4 .TRANSFORMER, CURRENT, 3000:5, 50-400 HZ 370351 4
T100 .TRANSF, POTENTIAL; 480V PRI, 120V SEC, 371046 1
+/-1% ACC @ 1.0 & .95 PF, 50/60 HZ
F100-102 .FUSE CARTRIDGE, 1 AMP, 600 VAC 324449 3
TIME DELAY CLASS CC
XF100-102 .FUSEBLOCK CLASS CC 600V REJ TYPE 324998 1
M1 .DIGITAL POWER METER 338272 1
CR30 .BRIDGE RECTIFIER 35A, 600V 354821 1
C30 .CAPACITOR, ELECTROLYTIC 250V, 100 MFD. 222097 1
OPTION #31: DIGITAL POWER METERING D29785-4
CT1,2 .TRANSFORMER, CURRENT, 2000:5 370157 2
F100-102 .FUSE CARTRIDGE, 1 AMP, 600 VAC 324449 3
TIME DELAY CLASS CC
XF100-102 .FUSEBLOCK CLASS CC, 600V REJ TYPE 324998 1
M1 .DIGITAL POWER METER 3 PHASE A22821 1
OPTION #32: DIGITAL METERING UNIT (DZ STYLE) D30857-2
CT1-2 .TRANSFORMER, CURRENT, 4000:5 371053 2
T100 .TRANSF, POTENTIAL; 480V PRI, 120V SEC, 371046 1
+/-1% ACC @ 1.0 & .95 PF, 50/60 HZ
F100-102 .FUSE CARTRIDGE, 1 AMP, 600 VAC 324449 3
TIME DELAY CLASS CC
XF100-102 .FUSEBLOCK CLASS CC 600V REJ TYPE 324998 1
M1 .DIGITAL POWER METER 338272 1
CR30 .BRIDGE RECTIFIER 35A, 600V 354821 1
C30 .CAPACITOR, ELECTROLYTIC 250V, 100 MFD. 222097 1
