Options Parts List
Avtron Model K875A Load Bank
6-15
Form No. 755A
SCHEMATIC
REFERENCE
DESCRIPTION
AVTRON
P/N
QTY/
UNIT
OPTION #33: DIGITAL METERING UNIT D29421-3
CT1,2 .TRANSFORMER, CURRENT, 2500:5, 370331 2
50-400 HZ, WINDOW SIZE 4.75" X 3.75"
T100 .TRANSF, POTENTIAL; 480V PRI, 120V SEC, 371046 1
+/-1% ACC @ 1.0 & .95 PF, 50/60 HZ
F100-102 .FUSE CARTRIDGE, 1 AMP, 600 VAC 324449 3
TIME DELAY CLASS CC
XF100-102 .FUSEBLOCK CLASS CC 600V REJ TYPE 324998 1
M1 .DIGITAL POWER METER W/OPTIONS A21449-6 1
85(FREQ)55(KVAR)79(PF)67(KVA)
CR30 .BRIDGE RECTIFIER 35A, 600V 354821 1
C30 .CAPACITOR, ELECTROLYTIC 250V, 100 MFD. 222097 1
OPTION #35: DIGITAL METERING UNIT D30857-3
(DZ STYLE), CT RATIO 2000:5, RS485
CT1-2 .TRANSFORMER, CURRENT, 2000:5 370157 2
T100 .TRANSF, POTENTIAL; 480V PRI, 120V SEC, 371046 1
+/-1% ACC @ 1.0 & .95 PF, 50/60 HZ
F100-102 .FUSE CARTRIDGE, 1 AMP, 600 VAC 324449 3
TIME DELAY CLASS CC
XF100-102 .FUSEBLOCK CLASS CC 600V REJ TYPE 324998 1
M1 .DIGITAL POWER METER 338288 1
CR30 .BRIDGE RECTIFIER 35A, 600V 354821 1
C30 .CAPACITOR, ELECTROLYTIC 250V, 100 MFD. 222097 1
OPTION #36: REMOTE MONITORING CONTACTS B27730
K101-103 .RELAY, 3PDT 351060 3
XK101-103 .SOCKET, RELAY 358280 3
XK101-103 .SPRING, HOLD DOWN 467550 3
OPTION #37: DIGITAL METERING UNIT D29421-4
CT1,2 .TRANSFORMER, CURRENT, 1500:5 370159 2
T100 .TRANSF, POTENTIAL; 480V PRI, 120V SEC, 371046 1
+/-1% ACC @ 1.0 & .95 PF, 50/60 HZ
F100-102 .FUSE CARTRIDGE, 1 AMP, 600 VAC 324449 3
TIME DELAY CLASS CC
XF100-102 .FUSEBLOCK CLASS CC 600V REJ TYPE 324998 1
M1 .DIGITAL POWER METER W/OPTIONS A21028-6 1
85(FREQ)55(KVAR)79(PF)67(KVA)
CR30 .BRIDGE RECTIFIER 35A, 600V 354821 1
C30 .CAPACITOR, ELECTROLYTIC 250V, 100 MFD. 222097 1
OPTION #38: DIGITAL POWER METERING D29785-5
CT1,2 .TRANSFORMER, CURRENT, 4000:5 371053 2
F100-102 .FUSE CARTRIDGE, 1 AMP, 600 VAC 324449 3
TIME DELAY CLASS CC
XF100-102 .FUSEBLOCK CLASS CC, 600V REJ TYPE 324998 1
M1 .DIGITAL POWER METER 3 PHASE A22821 1
