Avtron K875A - Page 61

Options Parts List
Avtron Model K875A Load Bank
6-16
Form No. 755A
SCHEMATIC
REFERENCE
DESCRIPTION
AVTRON
P/N
QTY/
UNIT
OPTION #39: DIGITAL METERING UNIT D30857-4
(DZ STYLE), CT RATIO 1200:5, RS485
CT1-2 .TRANSFORMER, CURRENT, 1200:5 370323 2
T100 .TRANSF, POTENTIAL; 480V PRI, 120V SEC, 371046 1
+/-1% ACC @ 1.0 & .95 PF, 50/60 HZ
F100-102 .FUSE CARTRIDGE, 1 AMP, 600 VAC 324449 3
TIME DELAY CLASS CC
XF100-102 .FUSEBLOCK CLASS CC 600V REJ TYPE 324998 1
M1 .DIGITAL POWER METER 338272 1
CR30 .BRIDGE RECTIFIER 35A, 600V 354821 1
C30 .CAPACITOR, ELECTROLYTIC 250V, 100 MFD. 222097 1
OPTION #40: DIGITAL METERING UNIT D30857-5
(DZ STYLE), CT RATIO 2500:5, RS485
CT1-2 .TRANSFORMER, CURRENT, 2500:5 370336 2
T100 .TRANSF, POTENTIAL; 480V PRI, 120V SEC, 371046 1
+/-1% ACC @ 1.0 & .95 PF, 50/60 HZ
F100-102 .FUSE CARTRIDGE, 1 AMP, 600 VAC 324449 3
TIME DELAY CLASS CC
XF100-102 .FUSEBLOCK CLASS CC 600V REJ TYPE 324998 1
M1 .DIGITAL POWER METER 338272 1
CR30 .BRIDGE RECTIFIER 35A, 600V 354821 1
C30 .CAPACITOR, ELECTROLYTIC 250V, 100 MFD. 222097 1
OPTION #41: CONTROL TRANSFORMER D27683-8
XF210-212 .FUSEBLOCK 3 POLE 324496 1
F212 .FUSE, CARTRIDGE, 12 AMP, 600V, 324468 1
TIME DELAY, CLASS RK-5
F210,211 .FUSE, 7 AMP, 600V, TIME DELAY CLASS RK-5 324697 2
T1 .TRANSFORMER, CONTROL 370824 1
OPTION #42: DIGITAL METERING UNIT D30857-6
(DZ STYLE), CT RATIO 1500:5
CT1-2 .TRANSFORMER, CURRENT, 1500:5 370159 2
T100 .TRANSF, POTENTIAL; 480V PRI, 120V SEC, 371046 1
+/-1% ACC @ 1.0 & .95 PF, 50/60 HZ
F100-102 .FUSE CARTRIDGE, 1 AMP, 600 VAC 324449 3
TIME DELAY CLASS CC
XF100-102 .FUSEBLOCK CLASS CC 600V REJ TYPE 324998 1
M1 .DIGITAL POWER METER 338272 1
CR30 .BRIDGE RECTIFIER 35A, 600V 354821 1
C30 .CAPACITOR, ELECTROLYTIC 250V, 100 MFD. 222097 1
