Replacement Parts List
Avtron Outdoor Resistive Load Bank • Part Number K975A 994213
6-2
REPLACEMENT PARTS LIST
SCHEMATIC
REFERENCE
DESCRIPTION
AVTRON
P/N
QTY/
UNIT
Form No. 755
AVTRON MODEL K975A LOAD BANK, OUTDOOR K975A-
994213
.SCHEMATIC 997418 REF
.INSTALLATION, CAMLOK CONNECTORS D41573 1
J1-9 ..RECEPTACLE, BROWN 315577 9
J10-18 ..RECEPTACLE, ORANGE 315576 9
J19-27 ..RECEPTACLE, YELLOW 315575 9
J28-30 ..RECEPTACLE, GREEN 315064 3
..PROTECTIVE CAP 428028 30
RA1 .RESISTOR ASSEMBLY D24712 1
..RESISTOR ELEMENT 605820 48
..INSULATOR 411141 960
..SPRING 473042 96
..PIN, SPRING CLIP 461156 96
RA2 .RESISTOR ASSEMBLY D24712 1
..RESISTOR ELEMENT 605820 48
..INSULATOR 411141 960
..SPRING 473042 96
..PIN, SPRING CLIP 461156 96
RA3 .RESISTOR ASSEMBLY D26614 1
..RESISTOR ELEMENT A23312 18
..RESISTOR ELEMENT 605820 30
..INSULATOR 411141 960
..SPRING 473042 96
..PIN, SPRING CLIP 461156 96
RA4 .RESISTOR ASSEMBLY D24712 1
..RESISTOR ELEMENT 605820 48
..INSULATOR 411141 960
..SPRING 473042 96
..PIN, SPRING CLIP 461156 96
RA5 .RESISTOR ASSEMBLY D24712 1
..RESISTOR ELEMENT 605820 48
..INSULATOR 411141 960
..SPRING 473042 96
..PIN, SPRING CLIP 461156 96
RA6 .RESISTOR ASSEMBLY D26614 1
..RESISTOR ELEMENT A23312 18
..RESISTOR ELEMENT 605820 30
..INSULATOR 411141 960
..SPRING 473042 96
..PIN, SPRING CLIP 461156 96
.RELAY ASSEMBLY 997417 1
K6-29 ..RELAY 351885 24
R1 ..RESISTOR, 150 OHMS 100W 156015 1
S1 ..SWITCH, TEMP 363099 1
K4,5 ..RELAY B14796 2
XF206-209 ..FUSEHOLDER 324980 2
F207 ..FUSE, 10 AMP 324128 1
F206,208,209 ..FUSE, 5 AMP 324211 3
K64,65,74,75 ..RELAY B14711 4
F10-15 ..FUSE, 80 AMP 324420 6
