Avtron K975A - Page 36

Replacement Parts List
Avtron Outdoor Resistive Load Bank • Part Number K975A 994213
6-3
Form No. 755A
SCHEMATIC
REFERENCE
DESCRIPTION
AVTRON
P/N
QTY/
UNIT
F16-87 ..FUSE, 150 AMP 324463 72
CT1,2,3 ..TRANSFORMER, CURRENT, 3200:5 370050 3
S4,5,6 ..CONTROLLER, TEMP 491017 3
XS4,5,6 ..SOCKET 358311 3
XS6 ..THERMOCOUPLE A24741 1
XF210-212 ..FUSEHOLDER 324496 1
K41-43 ..RELAY, 120V, 4 POLE 350676 3
K99 ..RELAY, 24 VDC, 4 POLE 350605 1
CR99 ..RECTIFIER 354585 1
F210,211 ..FUSE, 6 AMP 324393 2
F212 ..FUSE, 15 AMP 324346 1
.CONTROL PANEL D49545 1
D49545 ..PCB, DEDICATED I/O PR01288 1
DS1 ..PILOT LIGHT (YELLOW) EI00817 1
S2 ..PUSHBUTTON (RED) EI00683 1
S1 ..PUSHBUTTON (GREEN) EI00684 1
..LED, YELLOW, 24VAC EI01047 1
..LED, RED, 24VAC EI00734 1
..LED, GREEN, 24VAC EI01046 1
..LAMP HOLDER EI00685 3
..CONTACT BLOCK, NO EI00686 2
..CONTACT BLOCK, NC EI00687 1
S500 ..SWITCH, SELECTOR EI00744 1
XS500 ..CONNECTOR EI01845 1
.COMPONENT ASSEMBLY D49453 1
F200-205 ..FUSE, 30 AMP 324284 6
XF200-205 ..FUSEBLOCK 324997 2
K61,71 ..RELAY (WITH AUX) B14711 2
S2,3 ..SWITCH, SENSING 360772 2
K62,72 ..RELAY, OVERLOAD 350980 2
XK62,72 ..BRACKET, MOUNTING 408304 2
K130,131 ..RELAY, 24 VDC, 4 POLE 350605 2
CR130,131 ..RECTIFIER 354585 2
B1,2 .PANEL, FAN D30842-3 2
.CONTROL ASSEMBLY 997419 1
PS2 ..SUPPLY, POWER, 24 VDC, 2A EI01681 1
PS1 ..SUPPLY, POWER, 24 VDC, 1A EI01680 1
K100-126 ..RELAY, 24 VDC, FORM C, W/SOCKET EI01531 27
PT1-3 ..POTENTIAL TRANSFORMER W/DIVIDER EI00136 3
PT4,5 ..TRANSFORMER, 0-415V EI00430 2
A2 ..ASSEMBLY, BURDEN, CT PR00997 1
A1 ..CONTROLLER, SIGMA 2 PR01229 1
XA1 ..CONNECTOR, 3 POSITION EI01648 1
XA1 ..CONNECTOR, 10 POSITION EI01652 6
XA1 ..CONNECTOR, 9 POSITION EI01651 3
XPT1-5 ..RESISTOR, 16 OHM EO00404 5
XPT1-5 ..RESISTOR, 10 OHM EO00403 5
XA1 ..CONNECTOR, 7 POSITION EI01650 1
XF500-505 ..FUSEHOLDER 324998 2
F500-505 ..FUSE, 1 AMP 324815 6
XS4-5 .THERMOCOUPLE A23313 2
T1 .TRANSFORMER, 3KVA 371460 1
B3-5 .FAN 322190 3
.CONNECTOR SET KIT A33917 1
PH A ..CONNECTOR, FEMALE, BROWN 315725 9
PH B ..CONNECTOR, FEMALE, ORANGE 315726 9
