23
Fig. 1
trol to enable the even spooling of the wire around the drum. This reduces wire wear and
lengthens its lifetime.
- If extension cord is used, it must necessarily have following values. The extension cord
must always be completely uncoiled before use.
Voltage Length of extension cord Cross-sectional area of
the cord
220:240 V Less than 20 m 1,6 mm
2
220:240 V 20-50 m 2,5 mm
2
‐ When using hooks or pulleys, you must ensure their compatibility with the hoist. The ca-
pacity of the pulley must be at least double the capacity of the hoist. Do not use pulleys or
accessories that are incompatible with the hoist.
Operation
IMPORTANT! IN CASE OF EMERGENCY, PUSH THE RED EMERGENCY STOP BUTTON
TO SWITCH OFF THE HOIST.
- Do not exceed the maximum lifting capacity indicated in the rating plate.
- Always wear leather gloves when handling the wire. Keep your hands and other body
parts away from the hoist and wire during lifting.
- Never leave the hoist working unattended.
- There is no overload protection in the hoist to avoid abrupt after starting of the appliance.
- If the hoist does not lift the load in normal conditions, stop the hoist within 5 seconds.
- You must not lift any load forcibly but let the motor cool down.
- Do not subject the hoist to a sudden load.
- You must always leave at least five rounds of wire around the drum.
- Never coil the wire first around the load and then back around the drum. Always use the
wire hook to prevent the wire from fraying or kinking.
- Keep the cable of the remote switch away from the wire of the hoist.
- Spool the wire evenly around the drum after use. It is recommended to use the remote
control for spooling if possible.
- If you detect abnormally strong noise or vibration in the hoist while in operation, stop it
immediately and take it to an authorized service centre for inspection and possible repair.
WRONG WRONG
RIGHT
