TECHNICAL DATA
Cordless drill
Voltage 18 V
No load speed 0–400/0-1450 rpm
Chuck size 10 mm
Drilling capacities steel 8 mm and wood 20 mm
Torque settings 16+1
Max. torque 20 Nm
Dimensions 205 x 78 x 215 mm
Weight 1.23 kg
Battery
Cell type Li-ion
Voltage 18 V
Capacity 1.3 Ah / 23.4 Wh
Charger
Input power 100-240 V 50/60 Hz, 45 W
Output power 21 V DC, 1300 mAh
Cable length 1.8 m
Protection class II
Charging time 1 h (1.3 Ah)
Noise and vibration values
Sound pressure level, LpA 90 dB (A)
Sound power level, LwA 79 dB (A)
Uncertainty K 3 dB
Vibration (weighted) 1.339 m/s
2
Uncertainty K 1.5 m/s
2
This product fulfils the requirements of quality class HA 2807.
The sound intensity level for the operator may exceed 85 dB (A) and sound protection
measures are necessary.
WARNING: Always wear ear protection where the sound level exceeds 85 dB (A) and limit
the time of exposure if necessary. If sound levels are uncomfortable, even with ear protec-
tion, stop using the tool immediately and check the ear protection is correctly fitted and pro-
vides the correct level of sound attenuation for the level of sound produced by your tool.
WARNING: User exposure to tool vibration can result in loss of sense of touch, numbness,
tingling and reduced ability to grip. Long-term exposure can lead to a chronic condition. If
necessary, limit the length of time exposed to vibration and use anti-vibration gloves. Do not
operate the tool with hands below a normal comfortable temperature, as vibration will have
a greater effect. Use the figures provided in the specification relating to vibration to calcu-
late the duration and frequency of operating the tool. Sound and vibration levels in the spec-
ification are determined according to EN 62841 or similar international standards. The fig-
ures represent normal use for the tool in normal working conditions. A poorly maintained,
incorrectly assembled, or misused tool, may produce increased levels of noise and vibration.
