PRODUCT DESCRIPTION
This machine is intended for the drilling of wood, plastic and metal. All other use is absolute-
ly forbidden.
Parts
1. Chuck Jaws
2. Chuck Collar
3. Chuck Rear Collar
4. Torque Selector
5. Gear Selector
6. Motor Vents
7. Forward/Reverse Switch
8. Main Handle
9. Battery Slot
10. Battery
11. Battery Release
12. Trigger Switch
13. LED Worklight
14. LED Charge Indicator
15. DC plug
16. Charger base
17. Charger
PRIOR TO USE
Unpack the appliance and check that all parts are included. If any part is missing or dam-
aged, contact your dealer immediately. Dispose all packing material according to local regu-
lations.
Removing the battery from the drill
To remove the Battery from the drill, press the Battery Release and pull the Battery forwards
out of the Battery Slot at the base of the drill.
Installing a charged battery
1. To fit a charged Battery to the drill, slide it into the Battery Slot. Note: The Battery will fit
only in one direction, which is determined by its shape and the design of the battery hous-
ing. However, if the Battery does not slide into the housing easily, do not force it. Instead,
pull the Battery out of the housing again, check for correct position, and try again gently.
To Next Page
