Awntech Full Cassette - Motor and Remote Operation; Remote Control Model DC90

Page | 13
REMOTE CONTROL MODEL – DC90 FOR AT45MR
The Awntech tubular motor operates at a maximum distance of 150 Feet.
Technical Specification:
▪ Power Supply
▪ Protection index
▪ Working temp.
▪ 12V Battery
▪ IP30
▪ 23 degree F to 160 degree F
Beauty-Mark® motorized awnings are programmed to extend and retract fully. This motor has manual over-ride
option available. In case of power failure you can retract or extend the awning by using the rocker handle.
Replacement:
To Change the batter, open the back panel of the remote control and replace the battery.
Trouble Shooting:
 If the LED light on the remote control is off:
 Check the battery
 If the LED light is red on the remote control and the motor does not function:
 Check the power supply to the motor
 Check the cable connections
 The motor has an internal temperature control and shuts off the motor. Wait (20) twenty minutes and try
to operate.
If you have any questions. Contact our technical support team at 800-203-7049 M-F (9-5 CST)
Programming the remote control
To program the Remote Control (transmitter)
 Turn off the power source of the awning
 Turn on the power source. Within six seconds, press the “Program” (P2) button twice (located in the
battery compartment of the remote) then press the “UP” Button once.
To change the direction
 Turn off the power source of the awning
