AWS M Series User Manual

V1.3
１３
Charge Parameters (optional)
Rated battery voltage
48Vdc
240Vdc
Temperature
compensation function
(optional)
-3mV/
℃
/2V
Output Parameters
Rated output voltage
48Vdc
240Vdc
Start unload voltage
56Vdc (factory default,
44Vdc~64Vdc settable)
280Vdc (factory default,
220Vdc~320Vdc settable)
Complete unload
voltage
60Vdc (factory default, add 4V to
the start unload voltage)
300Vdc (factory default, add 20V to
the start unload voltage)
Max. Output current
21Adc
5Adc
General Parameters
Rectifier mode
Uncontrolled rectifier
Display mode
LCD
Display information
DC output voltage, wind turbine voltage/current/power.
For those with charge control function, Battery voltage is showed as well.
Monitoring mode
(optional)
RS232/RS485/RJ45/GPRS/ Bluetooth /Zigbee
Monitoring Contents
Real-time display: DC output voltage, wind turbine voltage/current/power.
For those with charge control function, Battery voltage is showed as well.
Parameter setting: Output overvoltage point, wind turbine over current point,
wind turbine start voltage, and wind turbine brake settings.
Lightning protection
YES
Conversion efficiency
≥92%
Static loss
＜
2W
＜
2W
Ambient temperature
-20
℃
～
+40
℃
Humidity
0~90%, No condensing
Noise
≤65dB
Cooling mode
Forced air cooling
Installation mode
Wall-mounted
Cover protection class
IP42

AWS M Series Specifications

General

Brand	AWS
Model	M Series
Category	Controller
Language	English
