AWS M Series User Manual

V1.3
１５
Brake by over wind
speed (optional)
18m/s (0-30m/s settable),Unload completely when reached the set wind
speed, and recover automatically after working 10mins.
Brake by over
rotational Speed
(optional)
500r/min (factory default,0~1000r/min settable)Unload completely when
reached the set rotational speed, and recover automatically after working
10mins.
Charge Parameters (optional)
Rated battery voltage
48Vdc
Temperature
compensation
function (optional)
-3mV/
℃
/2V
Output Parameters
Rated output voltage
48Vdc
Start unload voltage
56Vdc (factory default,44Vdc~64Vdc settable)
Complete unload
voltage
60Vdc (factory default, add 4V to the start unload voltage)
Max. Output current
42A
General Parameters
Rectifier mode
Uncontrolled rectifier
Display mode
LCD
Display information
DC output voltage, wind turbine voltage/current/power.
For those with charge control function, Battery voltage is showed as well.
Monitoring mode
(optional)
RS232/RS485/RJ45/GPRS/Bluetooth/Zigbee
Monitoring Contents
Real-time display: DC output voltage, wind turbine voltage/current/power.
For those with charge control function, Battery voltage is showed as well.
Parameter setting: Output overvoltage point, wind turbine over current point,
wind turbine start voltage, and wind turbine manual brake button.
Lightning protection
YES
Conversion efficiency
≥92%
Static loss
＜5W
Ambient temperature
-20℃～+40℃
Humidity
0~90%, No condensing
Noise
≤65dB
Cooling mode
Forced air cooling
Installation mode
Wall-mounted
Cover protection class
IP42
