AWS M Series User Manual

V1.3
１７
Brake by overvoltage
320Vdc (Factory
default), PWM unload
step by step once reached
the set unload voltage,
and it will unload
completely if the voltage
rise 20Vdc more.
Refer to “output overvoltage”
Brake by over wind
speed (optional)
18m/s (0-30m/s settable),Unload completely when reached the set wind
speed, and recover automatically after working 10mins.
Brake by over
rotational Speed
(optional)
500r/min (factory default,0~1000r/min settable)Unload completely when
reached the set rotational speed, and recover automatically after working
10mins.
Charge Parameters (optional)
Rated battery voltage
48Vdc
120Vdc
240Vdc
Temperature
compensation function
(optional)
-3mV/℃/2V
Output Parameters
Rated output voltage
48Vdc
120Vdc
240Vdc
Start unload voltage
56Vdc (factory
default,44Vdc~64Vdc
settable)
140Vdc (factory
default,110Vdc~160Vdc
settable)
280Vdc (factory
default,220Vdc~320Vdc
settable)
Complete unload
voltage
60Vdc(factory
default,add 4V to the
start unload voltage)
150Vdc (factory
default,add 10V to the
start unload voltage)
300Vdc (factory
default,add 20V to the
start unload voltage)
Max. Output current
63A
25A
13A
General Parameters
Rectifier mode
Uncontrolled rectifier
Display mode
LCD
Display information
DC output voltage, wind turbine voltage/current/power.
For those with charge control function, Battery voltage is showed as well.
Monitoring mode
(optional)
RS232/RS485/RJ45/GPRS/Bluetooth/Zigbee
Monitoring Contents
Real-time display: DC output voltage, wind turbine voltage/current/power.
For those with charge control function, Battery voltage is showed as well.
Parameter setting: Output overvoltage point, wind turbine over current point,
wind turbine start voltage, and wind turbine manual brake button.
