AWS M Series User Manual

V1.3
１９
Brake by over current
25A (factory default,0~25A settable)Unload completely
when reached the set current, and recover automatically
after working 10mins.
50A (factory
default,0~50A
settable)Unload
completely when
reached the set
current, and recover
automatically after
working 10mins.
Brake by overvoltage
320Vdc (factory
default,220Vdc~320Vdc
settable)PWM unload step by step
once reached the set unload voltage,
and it will unload completely if the
voltage rise 20Vdc more.
Refer to “output overvoltage” control
Brake by over wind
speed (optional)
18m/s (0-30m/s settable),Unload completely when reached the set wind
speed, and recover automatically after working 10mins.
Brake by over
rotational Speed
(optional)
500r/min (factory default,0~1000r/min settable)Unload completely when
reached the set rotational speed, and recover automatically after working
10mins.
Charge Parameters (optional)
Rated battery voltage
48Vdc
120Vdc
240Vdc
240Vdc
Temperature
compensation function
(optional)
-3mV/℃/2V
Output Parameters
Rated output voltage
48Vdc
120Vdc
240Vdc
240Vdc
Start unload voltage
56Vdc (factory
default,44Vdc~64
Vdc settable)
140Vdc (factory
default,110Vdc~1
60Vdc settable)
280Vdc (factory
default,220Vdc~320Vdc settable)
Complete unload
voltage
60Vdc (factory
default, add 4V to
the start unload
voltage)
150Vdc (factory
default, add 10V to
the start unload
voltage)
300Vdc (factory default,add 20V to
the start unload voltage)
Max. Output current
105A
42A
21A
42A
General Parameters
Rectifier mode
Uncontrolled rectifier
Display mode
LCD
Display information
DC output voltage, wind turbine voltage/current/power.
