axing ORX 1-00 User Manual

Operation Instructions | ORX 1-00 | CATV Optical Receiver
4
2017-10-24 | Technical improvements, changes in design, printing- and other errors expected.
1. Description
ORX 1-00 CATV optical receiver, compacted in size, designed for FTTH (Fiber To The Home) networks. ORX 1-
00 works under 1100~1650nm. ORX 1-00 is the new type micro optical receiver with LED optical power
indicator.
1.1. Delivery
Description Quantity
Optical Receiver Unit 1
External Power Supply Adapter 1
User’s Manual 1
1.2. Features
∂ Compacted in size with nice appearance
∂ AGC (Auto Gain Control) function
∂ Low power consumption <3W
∂ 0~10dB adjustable attenuator
∂ Low noise and high sensitive PIN Diode
∂ External power supply adapter
∂ Cost effective with high performance
1.3. Applications
∂ CATV, HFC networks
∂ FTTH, FTTB networks
∂ PON RF Overlay
1.4. Block Diagram
