5
30V 10/20A
F
I
N
E
COARSE
V
CAT
VOLTAGE
C. V.
COARSE
F
I
N
E
CRRENT
C. C.
ON O
OER
30/50V 2/3/5A15/18V
_
+
OFF ON
VOLTAGE
CURRENT
DC POWER
SUPPLY
I NE
ON O
OER
VOLTAGE
C. V.C. C.
COARSE
CRRENT
I NE COARSE
Earth ground.
Caution! Hot surface. Avoid contact.
Conforms to European Union directives.
Instrument Front panel
Figure 1-1
1. OUTPUT VOLTAGE INDICATOR
This indicator shows output voltage as measured at the output terminals.
There is LCD or LED or pointer meter display type. They are available for choice of user.
2. OUTPUT CURRENT INDICATOR
This indicator shows output current as measured at the output terminals.
There is LCD or LED or pointer meter display type. They are available for choice of user.
3. COARSE(MAIN) VOLTAGE REGULATOR
Adjust output voltage of the DC power supply.
4. FINE VOLTAGE REGULATOR
This is a fine control. Adjust output voltage of the DC power supply.
