8-9 Periodic Maintenance and Adjustment
Hood
To open
Unhook the hood latches, and then slowly tilt
the hood up until it stops.
1. Latch (×2)
1. Hood
To close
Lower the hood slowly to its original position,
and then hook the hood latches.
Secure projections on the underside of the ①
hood into slots o② n the back of the
instrument panel. Secure slots on the side ③
of the hood around projections on the ④
frame.
