Periodic Maintenance and Adjustment 8-10
1. Projection (×2) 2. Slot (×2)
3. Slot (×2) 4. Projection (×2)
CAUTION:
Make sure that all cables and wires are in
place when closing the hood.
Do not drive the vehicle with the hood
open, unlatched, or removed.
Console
To remove
1. Remove the seats. (See pages 4-17─
4-18 for seat removal and installation
procedures.)
2. Remove the parking brake lever boot.
3. Pull the console upward (the drive select
lever boot will come loose.)
1. Console
To Next Page
