SELECT DRILLING POSITION FOR SENSOR A&D

SELECT DRILLING POSITION FOR SENSOR B&C

A. Choose suitable drilling positions

for A and D sensor and mark.

For best detection angle, position A & D

sensor 1/8 from the edge.

A. Measure the distance between

sensor A and D.

Divide distance by 3 and mark sensor B & C.
