27191/EN/R4/0607
AXIS 207/207W/207MW Network Cameras
Specifications
AXIS 207/207W/207MW
Network Camera with flexible
clamp - clamp included
The four-pin terminal connector provides the interface to 1 alarm input, 1 output and
alternative power connection. It can be used for connecting e.g. an external alarm
device for triggering an alarm notification via email.
AXIS 207/207W/207MW Network
Camera with camera stand -
stand included
Models
AXIS 207: VGA, wired interface
AXIS 207W: VGA, wired and wireless interface
AXIS 207MW: Megapixel, wired and wireless interface
Image sensor
AXIS 207/207W: 1/4” Micron Progressive Scan RGB VGA CMOS
AXIS 207MW: 1/3” Micron Progressive Scan RGB 1.3 Megapixel CMOS
Lens
AXIS 207/207W: 4.0 mm, F2.0, horizontal viewing angle: 55°, fixed iris,
focus range: 0.5 m to infinity
AXIS 207MW: 3.6 mm, F1.8, horizontal viewing angle: 85°, fixed iris,
focus range: 0.5 m to infinity
Light
sensitivity
AXIS 207/207W: 1-10000 lux, F2.0
AXIS 207MW: 2-10000 lux, F1.8
Video
compression
Motion JPEG
MPEG-4 Part 2 (ISO/IEC 14496-2) with motion estimation, profiles:
Simple Profile, level 0-3, and Advanced Simple Profile, level 0-5
Resolutions
AXIS 207/207W: 7 resolutions up to 640x480
AXIS 207MW: 15 resolutions up to 1280x1024
Frame rate
AXIS 207/207W: Up to 30 fps in all resolutions
AXIS 207MW: Up to 14 fps in resolutions up to 1280x720, up to 12 fps
in 1280x1024
Video
streaming
Simultaneous Motion JPEG and MPEG-4
Controllable frame rate and bandwidth
3GPP and ISMA compatible
Image settings
Compression levels: 100
Rotation: 0°, 180°
Configurable color level, brightness, contrast, white balance
Overlay capabilities: time, date and text
Shutter time
AXIS 207/207W: 1/2 - 1/10000 second
AXIS 207MW: 1/10 - 1/10000 second
Audio
Built-in microphone for one-way audio
Audio compression:
AAC LC 8-32 kbit/s
G.711 PCM 64 kbit/s, G.726 ADPCM 32 or 24 kbit/s (AXIS 207W/
207MW)
Wireless
interface
(AXIS 207W/
207MW)
IEEE 802.11g 6 - 54 Mbps
IEEE 802.11b 1 - 11 Mbps
Transmit power: 20-22 dBm* (FCC), 11-14 dBm (CE)**
Receiver sensitivity: -90 dBm at 1 Mb
Modes: Infrastructure and ad-hoc
Antenna gain: 1.6 dBi
*Peak; without antenna gain; **Avg; without antenna gain
Security
Multiple user access levels with password protection
AXIS 207W/AXIS 207MW: IP address filtering, HTTPS encryption
WEP 64/128 bit, WPA-PSK*, WPA2-PSK*
*infrastructure mode only
Users
10 simultaneous unicast users
Unlimited users using multicast (MPEG-4)
Alarm
and event
management
Events triggered by video motion detection, audio or external input
Upload of MPEG-4 video or Motion JPEG images over FTP, email and HTTP
Notification via email, HTTP and external output
Pre- and post alarm buffering in MPEG-4 file up to 4 MB
(AXIS 207/207W) / 2 MB (AXIS 207MW)
Connectors
Ethernet 10BaseT/100BaseTX, Auto-MDIX (AXIS 207W/207MW), RJ-45
Terminal block for 1 alarm input, 1 output and alternative power
connection
Processors and
memory
CPU, video processing and compression: ARTPEC-A
RAM: 32 MB, Flash: 4 MB (AXIS 207), 8 MB (AXIS 207W/207MW)
Power
AXIS 207: 4.9-5.1 V DC, max 2.5 W
AXIS 207W: 4.9-5.1 V DC, max 3.5 W
AXIS 207MW 4.9-5.1 V DC, max 4.0 W
Operating
conditions
5-50 °C (41-122 °F)
Humidity 20 - 80% RH (non-condensing)
Installation,
management
and
maintenance
Installation tool on CD and Web-based configuration
Configuration backup and restore
Video management software for recording
Firmware upgrades over HTTP or FTP, firmware available at
www.axis.com
Video access
from Web
browser
Camera live view,
video recording to file (ASF),
customizable HTML pages
Minimum
Web browsing
requirements
Pentium III CPU 500 MHz or higher, or equivalent AMD
128 MB RAM
AGP graphics card 32 MB RAM, Direct Draw
Windows XP, 2000, DirectX 9.0 or later
Internet Explorer 6.x or later
Mac OS X 10.3 or later and Safari 1.3 or later with QuickTime plugin
Other MPEG-4/AAC players supported: Packet Video, QuickTime,
RealPlayer standalone and browser plug-ins, Windows Media Player
For other operating systems and browsers see www.axis.com/techsup
System
integration
support
Powerful API for software integration available at www.axis.com,
including AXIS VAPIX API, AXIS Media Control SDK, event trigger
data in video stream. Quality of Service (QoS) Layer 3, DiffServ Model.
Embedded operating system: Linux
Supported
protocols
IPv4, IPv6*, HTTP, HTTPS*, TCP, ICMP, RTSP, RTP, UDP, IGMP, RTCP,
SMTP, FTP, DHCP, UPnP, Bonjour, ARP, DNS, DynDNS, SOCKS, NTP, etc.
*AXIS 207W/207MW
More information on usage available at www.axis.com
This product includes software developed by the Open SSL Project for use in the
Open SSL Toolkit
Accessories
(included)
Power supply, stand, clamp, connector block, Installation Guide,
CD with installation tool, software and User’s Manual, AXIS Camera
Explorer license, MPEG-4 licenses (1 encoder, 1 decoder),
MPEG-4 decoder (Windows)
Video
management
software
(not incl.)
AXIS Camera Station - Surveillance application for viewing, recording
and archiving up to 25 cameras
See www.axis.com/partner/adp_partners.htm for more software
applications via partners
Accessories
(not incl.)
AXIS MPEG-4 Decoder multi-user license pack
AXIS 207: Indoor vandal-resistant housing
Approvals
AXIS 207: EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024,
EN 61000-6-1, FCC Part 15 Subpart B Class B, ICES-003 Class B,
VCCI Class B, C-tick AS/NZS 3548, EN 60950
AXIS 207W/207MW: EN 300328, EN 301489, FCC Part 15 Subpart B
& C Class B, ICES-003 Class B, RSS210, VCCI Class B, TELEC, C-tick
AS/NZS 4771, MIC, EN 60950
Power supply: EN 60950, UL, CSA
Dimensions
(HxWxD) and
weight
AXIS 207: 85 x 55 x 34 mm, (3.3” x 2.2” x 1.3”), 177 g (0.39 lb) incl.
stand, excl. power supply
AXIS 207W/207MW: 85 x 55 x 40 mm (3.3” x 2.2” x 1.6”) antenna not
included, 190 g (0.42 lb) incl. stand, excl. power supply
©2006 Axis Communications AB. The Axis trademark is registered by Axis AB. All other company names and products are trademarks or
registered trademarks of their respective companies. We reserve the right to introduce modifications without prior notice.
www.axis.com
