Axis 211M Datasheet

Technical specications – AXIS 211M Network Camera
www.axis.com
©2009 Axis Communications AB. AXIS COMMUNICATIONS, AXIS, ETRAX, ARTPEC and VAPIX are registered trademarks or trademark applications of Axis AB
in various jurisdictions. All other company names and products are trademarks or registered trademarks of their respective companies. We reserve the right
to introduce modications without notice.
37383/EN/R1/0911
Camera
Image sensor 1/3” Progressive scan RGB CMOS 1.3 Megapixel
Lens 3.0 - 8.0 mm, F1.0, DC-iris, CS mount
Angle of view, horizontal: 37° - 93°
Minimum
illumination
1 lux, F1.0
Shutter time 1/15000 s to 1/4 s
Video
Video
compression
MPEG-4 Part 2 (ISO/IEC 14496-2)
Motion JPEG
Resolutions 160x90 - 1280x1024
Frame rate
MPEG-4
Up to 8 fps at 1280x1024, 13 fps at 1024x768,
20 fps in 800x600 mode
Frame rate
Motion JPEG
Up to 12 fps at 1280x1024, 20 fps at 1024x768,
30 fps in 800x600 mode
Video streaming Simultaneous MPEG-4 and Motion JPEG
Controllable frame rate and bandwidth
VBR/CBR MPEG-4
Image settings Compression, color, brightness, sharpness, contrast, white
balance, exposure control, exposure zones, rotation, backlight
compensation, mirroring, fine tuning of behavior at low light
Text and image overlay
Privacy mask
Audio
Audio streaming Two-way, full, half duplex
Audio
compression
AAC LC 8 kHz 32 kbit/s
G.711 PCM 64 kbit/s
G.726 ADPCM 32 or 24 kbit/s
Audio input/
output
Built-in microphone, external microphone input or line input,
line level output
Network
Security Password protection, IP address filtering, HTTPS encryption,
IEEE 802.1X network access control, digest authentication,
user access log
Supported
protocols
IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour,
UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP,
TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
System integration
Application
Programming
Interface
Open API for software integration, including VAPIX®
from Axis Communications available at www.axis.com
Intelligent video Video motion detection, audio detection
Alarm triggers Intelligent video, external input
Alarm events File upload via FTP, HTTP and email
Notification via email, HTTP and TCP
External output activation
Video buffer 20 MB pre- and post alarm
General
Processors and
memory
ARTPEC-A, 64 MB RAM, 8 MB Flash
Power 7 - 20 V DC, max. 5 W
Power over Ethernet IEEE 802.3af Class 2
Connectors RJ-45 Ethernet 10BaseT/100BaseTX PoE, Auto-MDIX
Terminal block for 1 alarm input, 1 output and alternative power
connection
3.5 mm mic/line in, 3.5 mm line out
Operating
conditions
0 - 45 °C (32 - 113 °F)
Humidity 20 - 80% RH (non-condensing)
Approvals EN 55022 Class B, EN 55024, EN 61000-3-2, EN 61000-3-3,
FCC Part 15 Subpart B Class B, VCCI Class B, ICES-003 Class B,
C-tick AS/NZS CISPR 22, EN 60950-1
Power supply: EN 60950-1, UL, cUL
Weight 244 g (0.5 lb.)
Included
accessories
Power supply, stand, connector kit, Installation Guide, CD
with installation tools, recording software and User’s Manual,
Windows decoder 1-user license
Dimensions
More information is available at www.axis.com
Optional accessories
For information on AXIS Camera Station and
video management software from
Axis’ Application Development Partners, see
www.axis.com/products/video/software/
Various housings
Lenses
[5,2”]131 mm [2,1”]54 mm
[3,2”]80 mm
[2,5”]64 mm
[0,2”] 5 mm
[4,2”]107 mm
[5,2”]
132 mm
[3,4”]88 mm
[5,2”]131 mm [2,1”]54 mm
[3,2”]80 mm
[2,5”]64 mm
[0,2”] 5 mm
[4,2”]107 mm
[5,2”]
132 mm
[3,4”]88 mm
[5,2”]131 mm [2,1”]54 mm
[3,2”]80 mm
[2,5”]64 mm
[0,2”] 5 mm
[4,2”]107 mm
[5,2”]
132 mm
[3,4”]88 mm

Axis 211M Specifications

General

Maximum resolution	1280 x 1024 pixels
Camera shutter speed	1/15000 - 1/4 s
Minimum illumination	1 lx
Sensor type	CMOS
Progressive scan	Yes
Optical sensor size	1/3 \
Focal length range	3 - 8 mm
Power source type	PoE
Power consumption (typical)	5 W
Processor model	ARTPEC-A
Flash memory	8 MB
Internal memory	64 MB
I/O ports	1x RJ-45
Dimensions (WxDxH)	44 x 88 x 172 mm
Power requirements	DC 7 - 20V
Resolution description	1.3MP
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	244 g
