AXISCameraStationS22ApplianceSeries
Managethebuilt-inswitch
Managethebuilt-inswitch
Aboutthebuilt-inswitch
TheAXISCameraStationS22ApplianceSeriescomeswithanintegratedPoweroverEthernet(PoE)switch.Youcancongureand
managethebuilt-inswitch.
Thepurposeoftheswitchistosegregatetrafconthenetworksothatsecuritycamerasandrelatedtrafcmanagedbytheswitch
(PoEportsandU1networkconnections)arenotsharedwithothernetworks.
Theswitch’spowermanagementfollowtheserules:
Eachportcanreservepoweraccordingtotheconnectedpowereddevice’sPoEclass.Powercanalsobeallocatedmanually.
Iftheactualpowerconsumptionforagivenportexceedsthereservedpowerforthatport,itwillshutdown.
Portswillshutdownwhentheactualpowerconsumptionforallportsexceedsthetotalamountofpowerthatthe
powersupplycandeliver.Theportsarethenshutdownaccordingtotheportsprioritywherealowerportnumber
meanshigherpriority.
Logintotheswitch'smanagementpage
1.Gototheswitch’smanagementpage.
-Fromthewebbrowser,entertheswitch’sIPaddress.Bydefault:192.168.0.1
-FromAXISRecorderToolbox,gotoSwitch>Opentheswitchconguration.
-FromAXISCameraStationClient,gotoConguration>Switch>Management.SeeCongureswitch.
2.Loginwithyourcredentials.
-username:admin
-password:youcanndtherandomlygeneratedpasswordonastickerunderneaththeproductoraself-adhesive
stickerintheboxcontent.
Tologouttheswitch'smanagementpage,goto>Logout.
Overview
Intheswitch’smanagementpage,clickOverview.
Generalinformation
Category
ItemDescription
ActiveportsThenumberofportsthatareinuse.
PortsusingPoEThenumberofportswithPoEenabledthatareinuse.
Portssummary
LockedportsThenumberofportsthatarelocked.
CurrentPoEusage
ThetotalpowerinwattsandpercentageconsumedbythePoEdevices.
Clicktheporttoseethedetailsabouttheport.
ActiveTheportisinuse.
InactiveTheportisreadytobeused.
Portstatus
BlockedTheportisblocked.
31
