Productoverview
CAUTION
•IftwoPSUsareinstalled,boththePSUsmust
havethesametypeoflabel.Forexample,
ExtendedPowerPerformance(EPP)label.Mixing
PSUsfrompreviousgenerationsofPowerEdge
serversisnotsupported,evenifthePSUshave
thesamepowerrating.ThisresultsinaPSU
mismatchconditionorfailuretoturnthesystem
on.
•WhencorrectingaPSUmismatch,replaceonly
thePSUwiththeblinkingindicator.Swapping
thePSUtomakeamatchedpaircanresult
inanerrorconditionandunexpectedsystem
shutdown.Tochangefromahighoutput
congurationtoalowoutputcongurationor
viceversa,youmustturnoffthesystem.
•ACPSUssupportboth240Vand120Vinput
voltageswiththeexceptionofTitaniumPSUs,
whichsupportonly240V.Whentwoidentical
PSUsreceivedifferentinputvoltages,they
canoutputdifferentwattages,andtriggera
mismatch.
•IftwoPSUsareused,theymustbeofthesame
typeandhavethesamemaximumoutputpower.
•CombiningACandDCPSUsisnotsupportedand
triggersamismatch.
Powerindicators
LEDDescription
GreenAvalidpowersourceisconnectedtothePSUandthe
PSUisoperational.
Blinkingamber
IndicatesaproblemwiththePSU.
NotilluminatedPowerisnotconnected.
Blinkinggreen
Whenhot-pluggingaPSU,thePSUindicatorblinksgreen.
ThisindicatesthatthereisaPSUmismatchwithrespectto
efciency,featureset,healthstatus,orsupportedvoltage.
CAUTION
•WhencorrectingaPSUmismatch,replaceonly
thePSUwiththeblinkingindicator.Swapping
thePSUtomakeamatchedpaircanresult
inanerrorconditionandunexpectedsystem
shutdown.TochangefromaHighOutput
congurationtoaLowOutputcongurationor
viceversa,youmustturnoffthesystem.
•IftwoPSUsareused,theymustbeofthesame
typeandhavethesamemaximumoutputpower.
•CombiningACandDCPSUsisnotsupported
andtriggersamismatch.
Harddriveindicators
