AXISM1045-LWNetworkCamera
Additionalsettings
8.Inthelistofstorageoptions,selectSDcard.
9.ClickSave.
Advancedwirelesssettings
ThemostcommonsecuritymethodisWPA-/WPA2-PSK.ThisproductalsosupportsWPA
TM
-/WPA2
TM
-Enterprisewhichisamore
securemethod.Allsettingsmustmatchthesettingsintheaccesspoint.
WPA
TM
-/WPA2
TM
-PSK
ThesecuritymethodWPA-/WPA2–PSKisdesignedforsmallnetworksanddoesnotrequireanauthenticationserver.TheAxis
productusesaPSK(Pre-SharedKey)toauthenticatewiththeaccesspoint.Thekeycanbeenteredeitherasmanualhex—a64
hexdecimalnumber(0–9,A-F)—orapassphraseusing8–63ASCIIcharacters.Thelongerthepassphrase,themoresecureisthekey.
WPA
TM
-/WPA2-Enterprise
ThesecuritymethodWPA-/WPA2-Enterpriseisdesignedforlargenetworksandrequiresanauthenticationserver.Thenetworkis
protectedbyEAPOL(ExtensibleAuthenticationProtocolOverLan).
SelecttheWPA-Enterprisetypebeingusedbytheaccesspoint:
•EAP-TLS.Seepage11.
•EAP-PEAP/MSCHAPv2.Seepage11.
EAP-TLS
TheauthenticationprotocolEAP-TLS(ExtensibleAuthenticationProtocol-TransportLayerSecurity)allowstheclientandserverto
authenticateeachotherusingdigitalcerticatesprovidedbyaCerticationAuthority.Togainaccesstotheprotectednetwork,the
Axisproductpresentsitscerticatetothenetworkaccesspoint.Accessisgrantedifthecerticateisapproved.
Important
Toensuresuccessfulcerticatevalidation,timesynchronizationshouldbeperformedonallclientsandserverspriorto
conguration.
CongurethewirelesssettingsusingWPA
TM
-/WPA2-EnterpriseandEAP-TLS
1.GotoSettings>System>Wireless.
2.Inthelist,selectthewirelessnetwork.
3.UnderWPA-Enterprisetype,selectEAP-TLS.
4.EntertheuserIdentityassociatedwithyourcerticate.
5.SelecttheEAPOLversion(1or2)asusedintheaccesspoint.
6.SelecttheCAcerticateandtheclientcerticatetouseforwirelessauthentication.
7.ClickSave.
EAP-PEAP/MSCHAPv2
TheauthenticationprotocolEAP-PEAP/MSCHAPv2(ExtensibleAuthenticationProtocol-ProtectedExtensibleAuthentication
Protocol/MicrosoftChallengeHandshakeAuthenticationProtocol)allowstheclienttoauthenticatethenetworkusingadigital
certicateprovidedbyaCerticationAuthority.Thenetworkauthenticatestheclientusinganidentityandapassword.Togain
accesstotheprotectednetwork,theAxisproductpresentsitsidentityandpasswordtothenetworkaccesspoint.Ifthesecredentials
areapproved,theaccesspointallowsaccessonapreconguredport.
11

Axis M1045-LW Specifications

General

Form factor	Box
Sensor type	CMOS
Mounting type	Desk/Wall
Product color	White
Housing material	Aluminum
Optical sensor size	1/4 \
Progressive scan	Yes
Fixed focal length	2.8 mm
Maximum aperture number	2
Camera shutter speed	1/32000 - 1/5 s
Minimum illumination	0 lx
Field of view (FOV) angle	61 °
Type	IP security camera
PTZ modes	Digital PTZ
Languages support	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, KOR, POR, RUS
Number of languages	11
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video formats supported	H.264, M-JPEG, MPEG4
Image quality adjustment	Brightness, Contrast, Sharpness
Supported graphics resolutions	1920 x 1080 (HD 1080)
Audio system	2-way
Voice codecs	G.722.1, G.726
Audio formats supported	ADPCM, G.711, G.726, LC-AAC
Security algorithms	802.1x RADIUS, HTTPS, SNMP, SSL/TLS
Alert notification type	E-mail
Bluetooth	No
Wi-Fi standards	802.11a, 802.11b, 802.11g
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3af, IEEE 802.3at
Supported network protocols	IPv4/v6, HTTP , HTTPS a , SSL/TLS a , QoS Layer 3 DiffServ , FTP , CIFS/SMB, SMTP , Bonjour , UPnP T M , SNMPv1/v2c/v3 (MIB - II), DNS, DynDNS, NTP , RTSP , RTP , T CP , UDP , IGMP , RT CP , ICMP , DHCP , ARP , SOCKS
Minimum RAM	128 MB
Number of cameras	1
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Interface	RJ-45
LED type	IR
Night vision distance	10 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %
Power source type	DC
Power consumption (max)	4.4 W
Power consumption (typical)	2.7 W
Harmonized System (HS) code	85258900

Weight and Dimensions

Depth	37 mm
Width	60 mm
Height	106 mm
Weight	126 g
