AXISM1114
SetUptheProduct
SetUptheProduct
TheAxisproductcanbeconguredbyuserswithadministratororoperatorrights.Toopentheproduct’sSetuppages,clickSetupin
thetopright-handcorneroftheLiveViewpage.
•Administratorshaveunrestrictedaccesstoallsettings.
•OperatorshaveaccesstoallsettingsexceptSystemOptions
Seealsotheonlinehelp
.
BasicSetup
BasicSetupprovidesshortcutstothesettingsthatshouldbemadebeforeusingtheAxisproduct:
1.Users.Seepage38.
2.TCP/IP.Seepage40.
3.Date&Time.Seepage40.
4.VideoStream.Seepage16.
5.Focus.Seepage15
TheBasicSetupmenucanbedisabledfromSystemOptions>Security>Users.
FocusAdjustment
ThefocuscanbeadjustedunderBasicSetup>Focus.Followtheon-screeninstructionstoadjustthefocus.Forfurtherinformation
aboutfocus,refertotheproduct’sInstallationGuide.
BackFocusAdjustment
Ifthelensischangedtoanon-standardlensorwhenthefocusachievedisnotsatisfactory,adjustthebackfocusasfollows:
1.LoosenthescrewthatholdstheCS-ring.SeeHardwareOverviewonpage6
2.Directthecameratowardsanobjectatleast7metersawayandcheckthatitispossibletofocusthecamerainbothmax
wideandmaxteleangles(adjustwiththezoompuller).
3.Directthecameratowardsacloseobject,about30cmawayandcheckthatitispossibletofocusthecamerainbothmax
wideandmaxteleangles(adjustwiththezoompuller).
4.Ifitisnotpossibletofocusthecamerainstep2or3,adjusttheCS-ringandgobacktostep2.
5.GentlytightenthescrewtosecuretheCS-ring’sposition.
6.Adjustthezoomandfocuspositionforthedesiredview.
15
