Axis M3007–PV User Manual

AXISM3007-PVNetworkCamera
Video
Shutter&Gain
Theshutterandgainsettingsaffecttheamountofmotionblurandnoiseintheimage.Toadapttodifferentlighting,available
storagespaceandbandwidth,itisoftennecessarytoprioritizeeitherlowmotionblurorlownoise.TheAxisproductallowsdifferent
prioritizationinnormallightandinlowlight.
Shutterspeedisrelatedtotheamountoftimetheshutterisopenedandismeasuredinseconds(s).Aslowshutterspeedallows
morelighttoreachthesensorandcanhelpproduceabrighterimageinlowlightsituations.Ontheotherhand,aslowshutter
speedcancausemovingobjectstoappearblurry.
SetWideDynamicRangetoWDROffandsetShutterto
•Autotosettheshutterspeedautomatically.Ifrequired,useMaxshuttertolimittheshutterspeedtopreventtheframe
ratefrombeingreduced.
•Fixedtouseaxedshutterspeed.
Gain,measuredindecibel(dB),istheamountofamplicationappliedtotheimage.Ahighgainmayprovideabetterimageinlow
lightsituationsbutwillincreasetheamountofimagenoise.
SetGainto
•Autotosetthegainautomatically.Ifrequired,useMaxgaintolimittheappliedgain.
•Fixedtouseaxedgain.
Example
Ifstoragespaceorbandwidthislimited,tryusingalowergain.Thiswillreduceimagenoiseandproducesmallerimageles.
Viewareas
Aviewareaisacroppedpartofthefullview.ItistreatedasavideosourceinLiveViewandhasitsownvideostreamandPTZ
settings.SeePTZ(PanTiltZoom)onpage26.TosetupaviewareagotoVideo>ViewAreas.Hereyoucandenethenameand
resolutionforaviewarea,setupaHomepositionandlocktothispositionifdesired.
TodenethevideostreamsettingsforeachviewareaclickontherespectiveviewareafromSetup>Video>VideoStream.
Seepage16.
YoucanselectaviewareathatyouhavesetupfromtheSourcedrop-downlistintheLiveViewpage.UsethePan,Tilt,Zoom
sliders,orclickontheoverviewmapatthebottomrighttozeroinonanarea.Thecurrentpositionisindicatedintheoverview
mapbyagreencircle.
Aboutoverlays
Overlaysaresuperimposedoverthevideostream.Theyareusedtoprovideextrainformationduringrecordings,suchasatimestamp,
orduringproductinstallationandconguration.
Aboutoverlaytext
Anoverlaytextcanincludethecurrentdateandtime,oratextstring.Whenusingatextstring,so-calledmodierscanbeusedto
display,forexample,thecurrentbitrateorthecurrentframerate.
Youcanchoosebetweenthefollowingtextoverlaysizes:
Size
TextheightBackgroundheight
Small
10pixels20pixels
Medium16pixels28pixels
Large21pixels36pixels
21

Axis M3007–PV Specifications

General

Total megapixels	5 MP
Maximum resolution	2592 x 1944 pixels
Supported video modes	-
Video formats supported	H.264
Angle of rotation	180 °
Minimum illumination	0.6 lx
Field of view (FOV) angle	187 °
Sensor type	CMOS
Optical sensor size	1/3.2 \
Optical zoom	- x
IP address filtering	Yes
Built-in HDD	No
Flash memory	128 MB
Type	IP security camera
Certification	EN 55022 Class B, EN 61000-6-1, EN 61000-6-2, EN 55024, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22, KCC Class B, IEC/EN/UL 60950-1, IEC 60529 IP42, IEC 62262 Class IK08
Placement supported	Indoor
Connectivity technology	Wired
Form factor	Dome
Mounting type	Ceiling/wall
Product color	White
International Protection (IP) code	IP42
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4/v6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Power source type	PoE
Power consumption (typical)	4.6 W

Weight and Dimensions

Weight	610 g
Cable length	2 m
