Axis P1245 User Manual

AXISP1245NetworkCamera
Aboutvideosettings
Tocreateanewproleormodifyanexistingprole,gotoSetup>Video>StreamProles.
ToselectadefaultstreamprolefortheLiveViewpage,gotoSetup>LiveViewCong.
AboutONVIFmediaproles
AnONVIFmediaproleconsistsofasetofcongurationsthatcanbeusedtochangemediastreamsettings.ONVIFmediaproles
canbeusedbyaclienttoconguremediastreamproperties.
TheONVIFMediaProlespagelistsallpreconguredproles.Theseprolesareincludedintheproductforquicksetup.Youcan
add,modifyorremoveONVIFmediaprolesfromthispage.
Aboutcamerasettings
TheVideo>CameraSettingspageprovidesaccesstoadvancedimagesettingsfortheAxisproduct.
Aboutimageappearance
TochangeImageAppearancegotothemenusunderSetup>Video>CameraSettings.
TheimageBrightnesscanbeadjustedintherange0–100,whereahighervalueproducesabrighterimage.
IncreasingtheSharpnesscanincreasebandwidthusage.Asharperimagemightincreaseimagenoiseespeciallyinlowlight
conditions.Alowersettingreducesimagenoise,butthewholeimagewillappearlesssharp.
TheContrastchangestherelativedifferencebetweenlightanddark.Itcanbeadjustedusingtheslidebar.
Aboutexposuresettings
Conguretheexposuresettingstosuittheimagequalityrequirementsinrelationtotemperaturevariationsinthescene.
Automaticgaincontrol-Thissettingisusedtoautomaticallyadjustthegaintoanappropriaterange,theweakertheimagesignal,
thestrongerthegain.SelecttheLinearorEqualizationautomaticgaincontrolmethod.Thelatterusesahistogramequalization
method,whichadjuststhegaindynamicallybydistributingthemostfrequentintensityvalues.
Gain-Gainistheamountofamplicationappliedtoanimagesignal.Moregainmeansmorecontrastandmoredetailsbutalso
morenoise.Themaxgainvalueissetforallscenes,butaffectsprimarilylowcontrastscenescontrollingtheamountofallowednoise
intheimage,whichinturnalsolimitsthecontrast.
Aboutoverlays
Overlaysaresuperimposedoverthevideostream.Theyareusedtoprovideextrainformationduringrecordings,suchasatimestamp,
orduringproductinstallationandconguration.
Aboutoverlaytext
Anoverlaytextcanincludethecurrentdateandtime,oratextstring.Whenusingatextstring,so-calledmodierscanbeusedto
display,forexample,thecurrentbitrateorthecurrentframerate.
Youcanchoosebetweenthefollowingtextoverlaysizes:
Size
TextheightBackgroundheight
Small
10pixels20pixels
Medium16pixels28pixels
Large21pixels36pixels
Itisalsopossibletodisplaytextwhenanactionruleistriggered,seeHowtoincludeoverlaytextinanactionrule.
20

Axis P1245 Specifications

General

Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired
Number of cameras	1
Mounting brackets included	Yes
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 85 %
Sensor type	CMOS
Optical sensor size	1/3 \
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Power source type	PoE
Power consumption (max)	4 W
Power consumption (typical)	2.5 W
Form factor	Covert
Mounting type	Ceiling/Wall/Desk
Product color	White
Housing material	Plastic, Steel
Networking standards	IEEE 802.3af, IEEE 802.3at
Ethernet interface type	Fast Ethernet
Supported network protocols	IPv4/v6, HTTP, HTTPS , SSL/TLS , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
Security algorithms	802.1x RADIUS, HTTPS
Camera shutter speed	1/32500 - 1/25 s
Minimum illumination	0.22 lx
Maximum resolution	1920 x 1020 pixels
Supported video modes	1080p
Video compression formats	H.264
Supported graphics resolutions	1920 x 1080 (HD 1080)
Harmonized System (HS) code	85258900

Weight and Dimensions

Depth	109 mm
Width	46 mm
Height	16.5 mm
Weight	72 g
