AXIS P1355/P1357 Installation Guide Page 13
ENGLISH
LED indicators
Status LED when using the Focus Assistant
LED Color Indication
Network Green Steady for connection to a 100 Mbit/s network. Flashes for network activity.
Amber Steady for connection to 10 Mbit/s network. Flashes for network activity.
Unlit No network connection.
Status Green Steady green for normal operation.
Note: The Status LED can be configured to be unlit during normal operation, or to
flash only when the camera is accessed. To configure, go to Setup > System
Options > LED settings. See the online help files for more information.
Amber Steady during startup, during reset to factory default or when restoring settings.
Red Slow flash for failed upgrade.
Power Green Normal operation.
Amber Flashes green/amber during firmware upgrade.
Status LED Color Indication
Green Step 4: Focus Assistant is enabled
Step 6: The lens is optimally adjusted
Amber Step 4: The camera has been moved, or an object has been inserted in front of
the lens. Exit and restart the Focus Assistant.
Step 6: The lens is less optimally adjusted
Red Step 4: The camera has been moved, or an object has been inserted in front of
the lens. Exit and restart the Focus Assistant.
Step 6: The lens is poorly adjusted
