Audioinput
1Tip2Ring
3Sleeve
Unbalancedmicrophone(withorwithoutelectret
power)orline
Electretpowerifselected
Ground
Balancedmicrophone(withorwithoutphantompower)
orline,“hot”signal
Balancedmicrophone(withorwithoutphantom
power)orline,“cold”signal
Ground
DigitalsignalRingpowerifselected
Ground
Stereounbalancedmicrophone(withorwithoutelectret
power)orline,“left”
Stereounbalancedmicrophone(withorwithout
electretpower)orline,“right”
Ground
Audiooutput
1Tip2Ring
3Sleeve
Channel1,unbalancedline,monoChannel1,unbalancedline,monoGround
Balancedline,“hot”signalBalancedline,“cold”signal
Ground
Stereounbalancedline,“left”Stereounbalancedline,“right”Ground
Channel1,unbalancedlineChannel2,unbalancedlineGround
4-pinterminalblockforaudioinputandoutput.
FunctionPinNotes
GND
1
Ground
Ringpower
2
12Vforexternalsource
Microphone/Linein
3
Microphone(analogordigital)orlinein(mono).5Vmicrophonebiasisavailable.
Lineout
4
Linelevelaudiooutput(mono).Canbeconnectedtoapublicaddress(PA)systemoran
activespeakerwithabuilt-inamplier.
2-pinterminalblockforlineout.
FunctionPinNotes
Lineout(+)
1
Lineaudioout
0VDC(-)
2
