AXISP3935-LRNetworkCamera

Thedeviceinterface

Thesesettingsareavailableforeachaudioinput.

Soundlevel:Adjustthesoundleveltoavaluefrom0–100,where0isthemostsensitiveand100theleastsensitive.Usethe

activityindicatorasaguidewhenyousetthesoundlevel.Whenyoucreateevents,youcanusethesoundlevelasacondition.

Youcanchoosetotriggeranactionifthesoundlevelrisesabove,fallsbeloworpassesthesetvalue.

Shockdetection

Shockdetector:Turnontogenerateanalarmifthedeviceishitbyanobjectorifitistamperedwith.

Sensitivitylevel:Movetheslidertoadjustthesensitivitylevelatwhichthedeviceshouldgenerateanalarm.Alowvalue

meansthatthedeviceonlygeneratesanalarmifthehitispowerful.Ahighvaluemeansthatthedevicegeneratesanalarm

evenwithmildtampering.

Accessories

I/Oports

Usedigitalinputtoconnectexternaldevicesthatcantogglebetweenanopenandclosedcircuit,forexamplePIRsensors,dooror

windowcontacts,andglassbreakdetectors.

UsedigitaloutputtoconnectexternaldevicessuchasrelaysandLEDs.YoucanactivateconnecteddevicesthroughtheVAPIX®

ApplicationProgrammingInterfaceorinthedeviceinterface.

Port

Name:Editthetexttorenametheport.

Direction:

indicatesthattheportisaninputport.indicatesthatit’sanoutputport.Iftheportiscongurable,

youcanclicktheiconstochangebetweeninputandoutput.

Normalstate:Clickopencircuit,andforclosedcircuit.

Currentstate:Showsthecurrentstateoftheport.Theinputoroutputisactivatedwhenthecurrentstateisdifferentfromthe

normalstate.Aninputonthedevicehasanopencircuitwhenit’sdisconnectedorwhenthereisavoltageabove1VDC.

Note

Duringrestarttheoutputcircuitisopen.Whentherestartiscomplete,thecircuitgoesbacktothenormalposition.Ifyou

changeanysettingsonthispage,theoutputcircuitsgobacktotheirnormalpositionsregardlessofanyactivetriggers.

Supervised

:Turnontomakeitpossibletodetectandtriggeractionsifsomeonetamperswiththeconnectiontodigital

I/Odevices.Inadditiontodetectingifaninputisopenorclosed,youcanalsodetectifsomeonehastamperedwithit(thatis,cut

orshorted).Tosupervisetheconnectionrequiresadditionalhardware(end-of-lineresistors)intheexternalI/Oloop.

Logs

Reportsandlogs
