AXISP7224VideoEncoder
HardwareOverview
HardwareOverview
1
2
3
4
5 6
7
8
9
10
10
11
1.
Videoinputs(4)
2.
Audioinput1
3.
Audioinput2
4.
Audiooutput1
5.
Controlbutton
6.
Restartbutton
7.
StatusLED
8.
PowerLED
9.
Audiomountingnut
10.
Busconnectors
11.
Partnumber(P/N)&Serialnumber(S/N).Theserialnumbermayberequiredduringtheinstallation.
ConnectorsandButtons
Fortechnicalspecications,seepage54.
BusConnector
Thebusconnectorsarethephysicalinterfacestothevideoencoderchassisthatprovidepower,network,RS485,andI/Oterminal
connections.
BNCConnector
Eachvideoinputisterminatedusingacoax/BNCconnector.Connecta75Ohmcoaxialvideocable;therecommendedmaximum
lengthis250m(800ft).
Note
75Ohmvideoterminationcanbeenabled/disabledforthevideoinputthroughtheproduct'swebpageatVideo&Audio>
CameraSettings>Videotermination.Thisterminationisenabledonfactorydefault.Incaseswheretheproductistobe
connectedinparallelwithotherequipment,foroptimumvideoquality,itisrecommendedthatterminationbeenabledfor
onlythelastdeviceinthevideosignalchain.
AudioConnector
TheAxisproducthasthefollowingaudioconnectors:
•Audioin(pink)–3.5mminputforamonomicrophone,oraline-inmonosignal(leftchannelisusedfromastereosignal).
6
