AXISP7304VideoEncoder
Specifications
NetworkLEDIndication
Green
Steadyforconnectiontoa1Gbit/snetwork.Flashesfornetworkactivity.
Amber
Steadyforconnectiontoa10/100Mbit/snetwork.Flashesfornetworkactivity.
UnlitNonetworkconnection.
SDcardslot
NO NO
NO
TICE TICE
TICE
•RiskofdamagetoSDcard.Donotusesharptools,metalobjects,orexcessiveforcewheninsertingorremovingthe
SDcard.Useyourngerstoinsertandremovethecard.
•Riskofdatalossandcorruptedrecordings.DonotremovetheSDcardwhiletheproductisrunning.UnmounttheSDcard
fromtheproduct’swebpagebeforeremoval.
ThisproductsupportsmicroSD/microSDHC/microSDXCcards.
ForSDcardrecommendations,seeaxis.com.
microSD,microSDHC,andmicroSDXCLogosaretrademarksofSD-3CLLC.microSD,microSDHC,microSDXCare
trademarksorregisteredtrademarksofSD-3C,LLCintheUnitedStates,othercountriesorboth.
Buttons
Controlbutton
Thecontrolbuttonisusedfor:
•Resettingtheproducttofactorydefaultsettings.SeeResettofactorydefaultsettingsonpage44.
Connectors
Busconnector
Thebusconnectorsarethephysicalinterfacestothevideoencoderchassisthatprovidepower,network,RS485,andI/Oterminal
connections.
BNCconnector
Eachvideoinputisterminatedusingacoax/BNCconnector.
Connecta75Ohmcoaxialvideocable;therecommendedmaximumlengthis250m(800ft).
Note
75Ohmvideoterminationcanbeenabled/disabledforthevideoinputthroughtheproduct'swebpageat.Videotermination
isenabledonfactorydefault.Iftheproductisconnectedinparallelwithotherequipment,foroptimumvideoquality,we
recommendedtoenablevideoterminationonlyforthelastdeviceinthevideosignalchain.
Networkconnector
RJ45EthernetconnectorwithPoweroverEthernet(PoE).
