AXISP7304VideoEncoder

Conﬁgureyourdevice

Setvideoinput

Tousethevideoencoder,youmustsetthevideoinputsfortheconnectedcameras(channels).Whenyoulogintoyourdeviceforthe

rsttime,theautomaticallydetectedvideoinputsforthecamerasaresettoAutomatic.

Tochangethevideoinputs:

1.GotoSystem>Videoinput.

2.SelectManualandselectthevideostandardandresolutionforeachchannelyouwanttochange.

3.ClickSavechanges&restart.

CongureQuadHDor4Kresolution

QuadHD(1440p)or4K(2160p)resolutionisonlysupportedonchannel1.Onceitisconguredonchannel1,channel3isdisabled.

YoumustmanuallycongureQuadHDor4Kresolution:

1.GotoSystem>Videoinput.

2.UnderChannel1,selectManual.

3.SelectthevideostandardandQuadHDor4Kresolution.

4.ClickSavechanges&restart.

Adjusttheimage

Thissectionincludesinstructionsaboutconguringyourdevice.Ifyouwanttolearnmoreabouthowcertainfeatureswork,go

toLearnmoreonpage37.

Levelthecamera

Toadjusttheviewinrelationtoareferenceareaoranobject,usethelevelgridincombinationwithamechanicaladjustment

ofthecamera.

1.GotoVideo>Image>andclick

2.Click

toshowthelevelgrid.

3.Adjustthecameramechanicallyuntilthepositionofthereferenceareaortheobjectisalignedwiththelevelgrid.

Monitorlongandnarrowareas

Usecorridorformattobetterutilizethefulleldofviewinalongandnarrowarea,forexampleastaircase,hallway,road,ortunnel.
