Axis Q1604 Datasheet

Dimensions
1.
AXISQ1602/Q1604
2.
AXISQ1614
3.
AXISQ1602lens
4.
AXISQ1604/Q1614lens
5.
AXISQ16–E
151 mm (6 in)
78 mm (3.1 in)
136 mm (5.4 in)
82 mm (3.2 in)
46 mm (1.8 in)
58 mm (2.2 in)
54 mm (2.1 in)
54 mm (2.1 in)
1
2
3
5
4
404 mm (15.9 in)
140 mm (5.5 in)
142 mm (5.6 in)
110 mm (4.3 in)
161 mm (6.3 in)
TechnicalSpecications-AXISQ16NetworkCameraSeries
Models
AXISQ1602/-E:ExtendedD1(768x576),indoor/outdoor
AXISQ1604/-E:1MP/HDTV720p,indoor/outdoor
AXISQ1614/-E:1MP/HDTV720p,indoor/outdoor
Camera
Imagesensor
ProgressivescanRGBCMOS1/3”
Lens
IRcorrected,CS-mount,Megapixelresolution
AXISQ1602/-E:DC-iris
AXISQ1604/-E,AXISQ1614/-E:P-Iris
AXISQ1602/Q1604/Q1614:Varifocal2.8–8mm:
100°–34°view
a
,F1.2
AXISQ1602-E/Q1604-E/Q1614–E:Varifocal2.8–8mm:
80°–34°view
a
,F1.2
DayandnightAutomaticallyremovableinfrared-cutlter
Minimum
illumination
AXISQ1602/-E:Color:0.05lux,F1.2,B/W:0.008lux,F1.2
AXISQ1604/-E:Color:0.1lux,F1.2,B/W:0.02lux,F1.2
WithWDR-dynamiccapture:Color:0.4lux,F1.2,B/W:0.06lux,
F1.2
AXISQ1614/-E:ExtendedD1:Color:0.05lux,F1.2,B/W:
0.008lux,F1.2;720p25/30fps:Color:0.1lux,F1.2,B/W:
0.02lux,F1.2;WithWDR-dynamiccapture:Color:0.4lux,F1.2,
B/W:0.06lux,F1.2;720p50/60fps:Color:0.2lux,F1.2,B/W:
0.04lux,F1.2
Shuttertime
AXISQ1602/-E:1/29500sto2s
AXISQ1604/-E:
1/24500sto2swithpowerlinefrequency50Hz
1/29500sto2swithpowerlinefrequency60Hz
WithWDR-dynamiccapture:
1/192sto1/37swithpowerlinefrequency50Hz
1/231sto1/44swithpowerlinefrequency60Hz
AXISQ1614/-E:
ExtendedD1and720p25/30fps:
1/24500sto2swithpowerlinefrequency50Hz
1/29500sto2swithpowerlinefrequency60Hz
720p25/30fpswithWDR-dynamiccapture:
1/192sto1/37swithpowerlinefrequency50Hz
1/231sto1/44swithpowerlinefrequency60Hz
720p50/60fps:
1/37000sto2swithpowerlinefrequency50Hz
1/43500sto2swithpowerlinefrequency60Hz
Video
Video
compression
H.264(MPEG-4Part10/AVC),H.264MainandBaselineProle,
MotionJPEG
Resolutions
AXISQ1602/-E:768x576to160x90
AXISQ1604/-E:1280x960
b
(1MP)to160x90
AXISQ1614/-E:720p25/30fps:1280x960
b
to160x90;
720p50/60fps:1280x720to160x90;ExtendedD1:768x576
to160x90
Framerate
AXISQ1602/-E:30fpsinallresolutions
AXISQ1604/-E:
25fpsin50Hzcapturemode
30fpsin60Hzcapturemode
AXISQ1614/-E:
ExtendedD1and720p25/30fps:
25fpswithpowerlinefrequency50Hz
30fpswithpowerlinefrequency60Hz
720p50/60fps:
50fpswithpowerlinefrequency50Hz
60fpswithpowerlinefrequency60Hz
Videostreaming
Multiple,individuallycongurablestreamsinH.264/MotionJPEG,
Controllableframerateandbandwidth,VBR/CBRH.264
Imagesettings
Compression,Color,Brightness,Sharpness,Contrast,White
balance,Exposurecontrol,Exposurezones,Backlight
compensation,WDR-dynamiccontrast,Finetuningofbehavior
atlowlight,Textandimageoverlay,Privacymask,Mirroring
ofimages
AXISQ1604/-E:WDR-dynamiccapture:Upto120dB
(0.4–400,000lux)dependingonscene
AXISQ1614/-E:WDR-dynamiccapture:Upto120dB
(0.4–400,000lux)dependingonscene,Auto-rotation,Shadow
andhighlightrecovery,Day/Nightshiftlevel
AXISQ1602/Q1604/Q1614:Rotation:0°,90°,180°,270°
includingCorridorFormat
Audio
AudiostreamingTwo-way
Audio
compression
AACLC8/16kHz,G.711PCM8kHz,G.726ADPCM8kHz
Congurablebitrate
AXISQ1614/-E:AACLC8/16/32kHz
Audio
input/output
Externalmicrophone,inputorlineinput,lineoutput
AXISQ1602/Q1604/Q1614:Built-inmicrophone(canbe
disabled)
AXISQ1614/-E:Externalbalanced/unbalancedmicrophoneor
lineinput,lineoutput
Network
SecurityPasswordprotection,IPaddressltering,HTTPS
c
encryption,
IEEE802.1X
c
networkaccesscontrol,Digestauthentication,User
accesslog
Supported
protocols
IPv4/v6,HTTP,HTTPS
c
,SSL/TLS
c
,QoSLayer3DiffServ,FTP,
CIFS/SMB,SMTP,Bonjour,UPnP
TM
,SNMPv1/v2c/v3(MIB-II),
DNS,DynDNS,NTP,RTSP,RTP,TCP,UDP,IGMP,RTCP,ICMP,
DHCP,ARP,SOCKS
