AXISQ6054MkIIIPTZNetworkCamera
Specications
Multiconnector
Terminalconnectorforconnectingexternalequipment:
•Audioequipment
•Input/Output(I/O)devices
•AC/DCpowersupply
Whenconnectingexternalequipment,aseparatelysoldAxismulticableisrequiredinordertomaintain
theproduct’sIPrating.Formoreinformation,see.
Multicableconnectors
Multicable overview
1
Camera multiconnector
2
Audio in (pink)
3
Audio out (green)
4
Power connector, 3 - pin
5
I/O terminal block, 6 - pin
Themulticableprovidesthefollowingconnectors:
Powerconnector-3-pinterminalblockusedforpowerinput.UseaSafetyExtraLowVoltage(SELV)
compliantlimitedpowersource(LPS)witheitheraratedoutputpowerlimitedto≤100Worarated
outputcurrentlimitedto≤5A.
DCpowerinputACpowerinput
Audioin(pink)-3.5mminputforamonomicrophone,oraline-inmonosignal(leftchannelisused
fromastereosignal).
Audioout(green)-3.5mmoutputforaudio(linelevel)thatcanbeconnectedtoapublicaddress(PA)
systemoranactivespeakerwithabuilt-inamplifier.Astereoconnectormustbeusedfortheaudioout.
I/Oterminalconnector-Usewithexternaldevicesincombinationwith,forexample,tamperingalarms,
motiondetection,eventtriggering,andalarmnotifications.Inadditiontothe0VDCreferencepointand
power(DCoutput),theI/Oconnectorprovidestheinterfaceto:
•Digitaloutput—ForconnectingexternaldevicessuchasrelaysandLEDs.Connected
devicescanbeactivatedbytheVAPIX®ApplicationProgrammingInterfaceorfromthe
product’swebpage.
•Digitalinput—Forconnectingexternaldevicesthatcantogglebetweenanopenand
closedcircuit,forexamplePIRdetectors,door/windowcontacts,andglassbreak
detectors.
20
