Howtoaccesstheproduct
Aboutthecontrolsintheliveviewwindow
ClicktheViewsizebuttonstoshowtheimageinfullsize(rightbutton)ortoscaledowntheimageto
tthebrowserwindow(leftbutton).
ClickWDRontoenableWDRinintensebacklightconditions.ClickWDRofftodisableWDRinlow
lightconditionsforoptimalexposure.
SelectastreamprolefortheliveviewwindowfromtheStreamProledrop-downlist.Forinformation
abouthowtocongurestreamproles,seepage22.
Theproductisequippedwithawipertoenablewipingoftheprotectivewindow.ClickStartwiper
tostartthewiper.ClickStopwipertostopthewiper.ClickStartwipersequencetoactivate
thewiperforasetamountoftime.Forinformationabouthowtocongurethewiper,seeHowto
setupthewiperonpage35.
Theproductcanbeequippedwithawashertoenablecleaningoftheprotectivewindow.ClickStart
washtostartthewashingsequence.Forinformationaboutthewashingsequenceandhowtoenable
andcongurethewasher,seeHowtosetupthewasheronpage35.
EnabletheWLilluminationbuttonfromLiveViewCong>ActionButtons.ClicktheOn/Offbuttons
tomanuallyactivateordeactiveWLillumination.
EnableordisableIRilluminationfromSetup>Video>CameraSettings.EnabletheIRillumination
buttonfromLiveViewCong>ActionButtons.ClicktheOn/Offbuttonstomanuallyactivate
ordeactiveIRillumination.
Clickthebuttonactivatetheproduct’soutputportforadenedperiodoftime.Forinformationabout
howtoenableandcongureoutputbuttons,seepage29.Theoutputbuttonnamemaydifferdepending
onthenameenteredintheI/OPortsconguration.
ClicktheOn/Offbuttonstomanuallyactivateorinactivetheproduct’soutputport.Forinformation
abouthowtoenableandcongureoutputbuttons,seepage29.
UsetheManualTriggerbuttontotriggeranactionrulefromtheliveviewwindow.Forinformation
abouthowtocongureandenablethebutton,seeAboutthemanualtriggeronpage12.
ClicktheFocusrecallplusbuttontosavethefocussettinginthecurrentpan/tiltrange.Forinformation
aboutthefocusrecallfunction,seepage13.
ClicktheFocusrecallminusbuttontoremovethefocusrecallareainthecurrentpan/tiltrange.For
informationaboutthefocusrecallfunction,seepage13.
ClickSnapshottosaveasnapshotofthevideoimage.Thisbuttonisprimarilyintendedforusewhen
theAXISMediaControlviewertoolbarisnotavailable.EnablethisbuttonfromLiveViewCong>
ActionButtons.
EnableordisabletheGatekeeperbyselectingOnorOfffromthedrop-downlist.Formoreinformation
abouttheGatekeeper,seepage31.
