AXISQ87BispectralPTZNetworkCameraSeries
Specifications
5
CongurableI/O
6
CongurableI/O
Powerconnector
4-pinterminalblockforpowerinput.
24VAC/DCpowerconnector
NO NO
NO
TICE TICE
TICE
Thissectionisvalidforproductspoweredby24VACand24VDConly.
Thistableisonlyvalidforthe24VACandthe24VDCpowerconnectors.
Position
24VAC24VDC
1
ProtectiveearthProtectiveearth
2
24VACPhase
+24V
3
24VACNeutral
0V
4
NotconnectedNotconnected
Illuminatorconnectors
20
